Airtac 6V Solenoid Valve 6V0510J04F200
2、Internal venting structure collects pilot air for centralized exhaust through R/S ports;
3、High-pressure die-cast aluminum alloy body features precision-machined inner bore for optimized flow path geometry and enhanced flow capacity;
4、Available in threaded and quick-insertion port types, compatible with base-mounted valve manifolds for space-efficient installation.
Category: Solenoid Valves | Brand: AIRTC | Series: 6V
AirTAC 6V0510J04F200 Solenoid Valve Specifications
- Model: 6V0510J04F200
- Type: 5/2-way single solenoid controlled (monostable)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow coefficient (Cv): 1.4
- Response time: ≤15ms (actuation), ≤20ms (release)
- Weight: 320g ±5% (with connector)
- Dimensions: 60mm(L) × 45mm(W) × 85mm(H)
- Seal material: Heat-resistant NBR (Nitrile) with fluorine rubber backup
- Temperature range: -20℃ to 80℃ (non-freezing conditions)
- Power consumption: ≤2.5W (DC), ≤3.5VA (AC)
- Protection rating: IP67 (connector installed)
- Port thread depth: 12mm (minimum engagement)
High-speed 5-port pneumatic valve optimized for bidirectional cylinder control. Features dual-pressure operation capability and anti-vibration design with copper alloy solenoid core. Includes LED manual override and surge protection circuitry. Requires 5μm filtered lubricated air (ISO 8573-1 class 4).
- Industrial automation sequencing systems
- Multi-position pneumatic grippers
- Packaging machine clamp rotation mechanisms
- Textile machinery tension control
- Beverage filling line actuators
- Plastic injection molding ejectors
Installation note:
Mount with M4 screws (recommended torque 1.2N·m). Maintain minimum
50mm clearance below valve for exhaust airflow. Lubricate using ISO VG32
turbine oil if operating below -5℃. Cycle test monthly during standby periods.
| Property | Property Value |
|---|---|
| sku | 6V0510J04F200 |
| Port Size | PT 1/2 |
| Standard Voltage | DC12V |
