Airtac 6V Solenoid Valve 6V0510M5A050
2、Internal venting structure collects pilot air for centralized exhaust through R/S ports;
3、High-pressure die-cast aluminum alloy body features precision-machined inner bore for optimized flow path geometry and enhanced flow capacity;
4、Available in threaded and quick-insertion port types, compatible with base-mounted valve manifolds for space-efficient installation.
Category: Solenoid Valves | Brand: AIRTC | Series: 6V
AirTAC 6V0510M5A050 Solenoid Valve Specifications
- Model: 6V0510M5A050
- Type: 5-port 2-position (5/2-way) double solenoid
- Port size: G1/8 (ISO228 standard)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage options: DC24V (±10%) with DIN43650 connector
- Response time: ≤15ms (open), ≤20ms (close)
- Flow coefficient (Cv): 0.25
- Seal material: NBR (nitrile butadiene rubber)
- Valve body material: Aluminum alloy (anodized finish)
- Temperature range: -5℃ to 80℃ (operating fluid)
- Ambient temperature: -20℃ to 60℃
- Protection rating: IP67 (dust-tight, waterproof immersion up to 1m)
- Weight: 450g ±5% (including connectors)
- Dimensions: 80mm(L) × 35mm(W) × 55mm(H)
- Mounting: Sub-base compatible (ISO 5599-1 standard)
High-flow 5/2-way pneumatic valve with dual solenoid operation, featuring bi-stable latching function for energy-saving applications. The hardened aluminum body withstands vibration up to 10Hz/2mm amplitude. Optimized flow path reduces pressure drop by 18% compared to previous generation models.
- Automated assembly line cylinder control
- Rotary indexing table actuators
- Plastic injection molding machine ejectors
- Textile machinery clamp systems
- Automotive tire assembly robots
Installation Guidelines:
Use with 5μm filtration (40μm for emergency). Maintain ≥1m distance from high-frequency inverters. For horizontal mounting, install exhaust silencers vertically downward. Lubrication not required (pre-lubricated seals).
Do NOT use with acetylene or oxygen media. Minimum cycle time: 0.3s. For continuous operation, maintain ambient temperature below 50℃.
| Property | Property Value |
|---|---|
| sku | 6V0510M5A050 |
| Port Size | M5 |
| Standard Voltage | AC220V |
