Airtac 6V Solenoid Valve 6V0510M5B050
2、Internal venting structure collects pilot air for centralized exhaust through R/S ports;
3、High-pressure die-cast aluminum alloy body features precision-machined inner bore for optimized flow path geometry and enhanced flow capacity;
4、Available in threaded and quick-insertion port types, compatible with base-mounted valve manifolds for space-efficient installation.
Category: Solenoid Valves | Brand: AIRTC | Series: 6V
AirTAC 6V0510M5B050 Solenoid Valve Technical Specifications
- Model: 6V0510M5B050
- Valve type: 5/2-way monostable (spring return)
- Port configuration: M5 threaded ports (5 ports)
- Effective area ratio: 1:1.2 (pilot valve to main valve)
- Operating pressure range: 0.05–1.0 MPa
- Proof pressure: 1.5 MPa
- Voltage variants: DC12V (±10%), DC24V (±10%)
- Coil insulation class: Class F (155℃)
- Power consumption: 1.2W (DC24V), 1.5W (DC12V)
- Response time: ≤15ms (excitation), ≤20ms (reset)
- Seal material: HNBR (Hydrogenated Nitrile) for oil/fuel resistance
- Ambient temperature: -5℃ to 60℃ (non-freezing)
- Vibration resistance: ≤55Hz, double amplitude ≤1.5mm
- Protection rating: IP67 (dust/water ingress protection)
- Weight: 280g ±5g (with coil)
- Dimensions: 53mm(L) × 40mm(W) × 70mm(H)
High-flow micro-valve with integrated silencer, optimized for high-cycle automation systems requiring rapid switching. Features anti-vibration terminals and surge-protected coil design. Requires 5μm filtration (ISO 8573-1 class 4) with maximum 5mg/m³ oil content. Compatible with ISO VG32 hydraulic oil environments.
- Robotic end-effector tool changers
- CNC machine tool clamping systems
- Automated pharmaceutical blister packaging
- Electric vehicle battery cooling circuits
- High-speed labeling machine actuators
Installation protocol:
Mount with M5x16mm screws (1.2Nm torque limit). Maintain ≥20mm clearance
from high-frequency inverters. Perform 50% duty cycle calibration during
initial 500 operation cycles.
| Property | Property Value |
|---|---|
| sku | 6V0510M5B050 |
| Port Size | M5 |
| Standard Voltage | DC24V |
