Airtac 6V Solenoid Valve 6V0510M5B200
2、Internal venting structure collects pilot air for centralized exhaust through R/S ports;
3、High-pressure die-cast aluminum alloy body features precision-machined inner bore for optimized flow path geometry and enhanced flow capacity;
4、Available in threaded and quick-insertion port types, compatible with base-mounted valve manifolds for space-efficient installation.
Category: Solenoid Valves | Brand: AIRTC | Series: 6V
AirTAC 6V0510M5B200 Solenoid Valve Technical Details
- Model: 6V0510M5B200
- Valve type: 5/2-way monostable (single solenoid)
- Port configuration: M5 threaded (ISO 228-1 G1/8 equivalent)
- Operating pressure range: 0.1–1.0 MPa (14.5–145 PSI)
- Voltage variants: DC24V (±10%), 3W coil power
- Response time: ≤20ms (at 0.5 MPa)
- Flow capacity: 450 l/min (Cv=0.54)
- Weight: 185g ±5g (including connector)
- Dimensions: 58mm(L) × 34mm(W) × 70mm(H)
- Body material: Reinforced PBT resin (UL94 V-0 rated)
- Seal compound: Heat-resistant HNBR (-15℃ to 120℃)
- Ambient temperature: -5℃ to 60℃ (non-freezing)
- Protection class: IP67 (dust/water resistant)
- Port orientation: Horizontal manifold mounting
High-speed directional control valve with integrated quick-connect terminals, optimized for repetitive cycling applications. Features surge suppression circuitry for extended coil life (≥30 million cycles). Compatible with ISO 8573-1 class 3 compressed air (lubricated or non-lubricated).
- Multi-axis pneumatic actuator sequencing
- Bottle capping machine indexing mechanisms
- Textile machinery air jet control
- Automated test equipment with rapid cycling
- Cleanroom-compatible production lines
Operational guidance:
Install with 15mm clearance above for heat dissipation. Use pulse-width modulation (PWM) drivers for energy efficiency. Lubricate every 5M cycles with ISO VG32 turbine oil when using dry air.
| Property | Property Value |
|---|---|
| sku | 6V0510M5B200 |
| Port Size | M5 |
| Standard Voltage | DC24V |
