Airtac 6V Solenoid Valve 6V0510M5C050
2、Internal venting structure collects pilot air for centralized exhaust through R/S ports;
3、High-pressure die-cast aluminum alloy body features precision-machined inner bore for optimized flow path geometry and enhanced flow capacity;
4、Available in threaded and quick-insertion port types, compatible with base-mounted valve manifolds for space-efficient installation.
Category: Solenoid Valves | Brand: AIRTC | Series: 6V
AirTAC 6V0510M5C050 Solenoid Valve Technical Specifications
- Model: 6V0510M5C050
- Valve type: 5-port/3-position closed center (with double solenoid)
- Port configuration: M5 (ISO G1/8 equivalent flow)
- Thread standard: Metric (M5x0.8)
- Operating pressure range: 0.15–0.8 MPa (21.7–116 PSI)
- Max flow rate: 750 l/min (Cv=1.3 at 0.5 MPa)
- Voltage variants:
- DC: 12V (±10%), 24V (±10%)
- AC: 110V (±10% 50/60Hz), 220V (±10% 50/60Hz)
- Power consumption: 1.6W (DC), 3.2VA (AC)
- Response time: ≤15ms (excitation), ≤20ms (de-excitation)
- Seal material: HNBR (Hydrogenated Nitrile) for improved oil resistance
- Temperature range: -10℃ to 80℃ (with 0℃ anti-freeze measures)
- Protection class: IP67 (dust tight & protected against temporary immersion)
- Weight: 290g ±5g (including coil)
- Dimensions: 55mm(L) × 42mm(W) × 76mm(H) (excluding connectors)
- Port positions: 2 inlet (P), 2 outlet (A/B), 1 exhaust (R/S)
- Manual override: Optional mechanical override button
High-flow directional control valve with dual coil configuration, engineered for precise mid-pressure pneumatic systems. Features anti-vibration coil design (M5 suffix) and gold-plated terminals for stable electrical contact. The aluminum alloy body with hard anodized finish ensures durability in humid environments. Requires 5μm filtered air with ISO 8573-1:2010 Class 3.4.2 air quality standards.
- Multi-axis pneumatic actuator control in CNC tool changers
- Clamping sequence control in injection molding machines
- Vacuum/pressure switching in semiconductor handling systems
- Material sorting gates in automated warehouses
- Dual-circuit safety systems in press machinery
Installation guidelines:
Mount with DIN rail adapter (optional A-06H bracket). Maintain minimum
15mm clearance below valve for exhaust management. Use copper-free
lubricants if manual override is engaged frequently. Cycle rate should
not exceed 5Hz for continuous operation.
| Property | Property Value |
|---|---|
| sku | 6V0510M5C050 |
| Port Size | M5 |
| Standard Voltage | AC 110V |
