Airtac 6V Solenoid Valve 6V0510M5C200
2、Internal venting structure collects pilot air for centralized exhaust through R/S ports;
3、High-pressure die-cast aluminum alloy body features precision-machined inner bore for optimized flow path geometry and enhanced flow capacity;
4、Available in threaded and quick-insertion port types, compatible with base-mounted valve manifolds for space-efficient installation.
Category: Solenoid Valves | Brand: AIRTC | Series: 6V
AirTAC 6V0510M5C200 Solenoid Valve Technical Specifications
- Model: 6V0510M5C200
- Type: 5/2-way monostable (pilot-operated)
- Port size: M5 (ISO G1/8 optional)
- Effective area: 10mm²
- Operating pressure: 0.1–0.9 MPa
- Voltage tolerance: ±10% (DC24V standard, AC options available)
- Response time: ≤15ms (at 0.5MPa)
- Flow coefficient (Cv): 0.14
- Seal material: Heat-resistant NBR (-20℃ to 80℃)
- Protection rating: IP67 (dustproof/water immersion resistant)
- Coil insulation class: Class F (155℃)
- Weight: 180g ±5g (with connector)
- Dimensions: 50mm(L) × 30mm(W) × 70mm(H)
- Port thread depth: 8mm (minimum engagement)
High-speed 5-port pneumatic valve optimized for precision sequencing in automated systems. Features dual-color LED status indication (red/green) and manual override button. The aluminum alloy body with hard anodizing ensures corrosion resistance in humid environments. Compatible with ISO 15407-1 standards.
- Multi-axis pneumatic actuator control
- Textile machinery shuttle systems
- Bottle cap sorting & capping machines
- Semiconductor wafer handling robots
- Food-grade pneumatic circuits (requires optional PTFE seals)
Operational note:
Maintain air quality ISO 8573-1:2010 Class 3.4.2 (max 5mg/m³ oil content).
For horizontal mounting, install drip-proof cover (accessory code: 6V-AC01).
- Electrical: DIN 43650 Form A connector
- Pneumatic: BSPP (parallel) threads with O-ring seal
- Fieldbus ready: Supports IO-Link protocol (requires 6V-IO module)
| Property | Property Value |
|---|---|
| sku | 6V0510M5C200 |
| Port Size | M5 |
| Standard Voltage | AC 110V |
