Airtac 6V Solenoid Valve 6V0510M5F050
2、Internal venting structure collects pilot air for centralized exhaust through R/S ports;
3、High-pressure die-cast aluminum alloy body features precision-machined inner bore for optimized flow path geometry and enhanced flow capacity;
4、Available in threaded and quick-insertion port types, compatible with base-mounted valve manifolds for space-efficient installation.
Category: Solenoid Valves | Brand: AIRTC | Series: 6V
AirTAC 6V0510M5F050 Solenoid Valve Technical Details
- Model: 6V0510M5F050
- Type: 5/2-way monostable (spring return)
- Port configuration: 5 ports, 2 positions
- Port size: PT1/8 (M5x0.8 thread standard)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage specification: DC24V ±10% (coil class F)
- Power consumption: 1.8W (2.4W max during activation)
- Response time: ≤15ms (at 0.5 MPa)
- Flow capacity: 850 l/min (Cv=1.2)
- Seal material: HNBR (Hydrogenated Nitrile) for oil/fuel resistance
- Temperature range: -20℃ to 80℃ (with 1℃/min thermal shock resistance)
- Protection rating: IP67 (dust/water resistant)
- Weight: 280g ±5g (with coil and connector)
- Dimensions: 54mm(L) × 40mm(W) × 75mm(H) (excluding fittings)
- Port thread depth: 9.5mm (minimum engagement requirement)
- Hysteresis: ≤0.03 MPa (pressure differential sensitivity)
High-flow directional control valve with shock-resistant aluminum body and gold-plated terminals. Features manual override capability and LED status indicator. Designed for rapid cycling applications requiring precise directional control in humid/dusty environments. Requires 5μm filtered air with ISO 8573-1:2010 Class 3.4.2 air quality.
- Automated assembly line actuators
- Plastic injection molding machine clamps
- CNC tool changers & rotary tables
- Food processing pneumatic circuits (FDA-compliant versions available)
- Battery manufacturing vacuum/pressure systems
Installation protocol:
Mount with M5x25mm stainless steel screws (1.2-1.5Nm torque).
Maintain minimum 15mm clearance below valve for exhaust airflow.
Lubricate using ISO VG32 turbine oil if operated below -10℃.
| Property | Property Value |
|---|---|
| sku | 6V0510M5F050 |
| Port Size | M5 |
| Standard Voltage | DC12V |
