Airtac 6V Solenoid Valve 6V0520J04A050
2、Internal venting structure collects pilot air for centralized exhaust through R/S ports;
3、High-pressure die-cast aluminum alloy body features precision-machined inner bore for optimized flow path geometry and enhanced flow capacity;
4、Available in threaded and quick-insertion port types, compatible with base-mounted valve manifolds for space-efficient installation.
Category: Solenoid Valves | Brand: AIRTC | Series: 6V
AirTAC 6V0520J04A050 Solenoid Valve Technical Details
- Model: 6V0520J04A050
- Type: 5/2-way mono-stable (direct acting)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.1–1.0 MPa
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow coefficient (Cv): 1.6
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Weight: 320g ±5% (excluding connector)
- Dimensions: 59mm(L) × 44mm(W) × 78mm(H)
- Seal material: HNBR (Hydrogenated Nitrile) for oil/fuel resistance
- Temperature range: -10℃ to 80℃ (with silicone seals optional up to 120℃)
- Power consumption: 2.8W (DC24V), 4.5VA (AC220V)
- Protection rating: IP67 (dustproof and waterproof)
- Port thread depth: 12mm (minimum engagement 9mm)
High-flow directional control valve with manual override function, featuring brass main body and stainless steel plunger for excellent durability in humid environments. The optimized magnetic circuit design ensures stable operation under voltage fluctuations (±10% tolerance). Requires 5μm filtered compressed air with lubrication (ISO 8573-1 class 3.4.3).
- Automated assembly line actuators
- Plastic injection molding machines
- Textile machinery cylinder control
- Food processing pneumatic systems (oil-free version available)
- Automotive testing equipment
- Semiconductor manufacturing tools
Installation guidelines:
Mount in vibration-free environment using M4 mounting screws (max torque 1.2N·m).
For horizontal installation, orient exhaust ports downward to prevent dust ingress.
Recommended maintenance: Cycle valve monthly if unused for extended periods.
| Property | Property Value |
|---|---|
| sku | 6V0520J04A050 |
| Port Size | PT 1/2 |
| Standard Voltage | AC220V |
