Airtac 6V Solenoid Valve 6V0520J04A200
2、Internal venting structure collects pilot air for centralized exhaust through R/S ports;
3、High-pressure die-cast aluminum alloy body features precision-machined inner bore for optimized flow path geometry and enhanced flow capacity;
4、Available in threaded and quick-insertion port types, compatible with base-mounted valve manifolds for space-efficient installation.
Category: Solenoid Valves | Brand: AIRTC | Series: 6V
AirTAC 6V0520J04A200 Solenoid Valve Specifications
- Model: 6V0520J04A200
- Type: 5-port 2-position (5/2-way) double solenoid
- Port size: PT1/4 (G1/4 optional)
- Effective flow rate: 1200 L/min (Cv=1.8)
- Operating pressure: 0.1–1.0 MPa
- Voltage: DC24V ±10% (Standard), other voltages available
- Power consumption: 2.5W (standard coil)
- Weight: 430g ±5% (with connectors)
- Dimensions: 55mm(L) × 40mm(W) × 78mm(H)
- Seal material: Heat-resistant NBR (Nitrile rubber)
- Temperature range: -5℃ to 80℃ (with silicone seal option up to 120℃)
- Response time: ≤25ms (at 0.5MPa)
- Protection rating: IP67 (dustproof/water immersion resistant)
- Port thread depth: 12mm (ISO standard)
High-flow directional control valve with dual manual override and LED status indicator. Features copper-free aluminum alloy body for chemical compatibility and zinc-nickel plating for corrosion resistance. Designed for high-cycle applications with 50 million operations lifespan. Requires 5μm filtered air with ISO 8573-1:2010 Class 3.4.3 air quality.
- Plastic injection molding machine clamp control
- Automated assembly line cylinder sequencing
- Textile machinery pneumatic actuators
- Semiconductor wafer handling robots
- Beverage filling station valve clusters
Installation guidelines:
Use vibration-resistant DIN43650 Form A connectors. Maintain minimum
15mm clearance below valve for heat dissipation. Lubricate seals with
ISO VG32 turbine oil if operating below -5℃.
| Property | Property Value |
|---|---|
| sku | 6V0520J04A200 |
| Port Size | PT 1/2 |
| Standard Voltage | AC220V |
