Airtac 6V Solenoid Valve 6V0520J04B200
2、Internal venting structure collects pilot air for centralized exhaust through R/S ports;
3、High-pressure die-cast aluminum alloy body features precision-machined inner bore for optimized flow path geometry and enhanced flow capacity;
4、Available in threaded and quick-insertion port types, compatible with base-mounted valve manifolds for space-efficient installation.
Category: Solenoid Valves | Brand: AIRTC | Series: 6V
AirTAC 6V0520J04B200 Solenoid Valve Technical Details
- Model: 6V0520J04B200
- Valve type: 5/2-way monostable (spring return)
- Port configuration: PT1/4 (G1/4 optional)
- Operation method: Double solenoid pilot-operated
- Operating pressure range: 0.15–1.0 MPa
- Proof pressure: 1.5 MPa
- Voltage variants: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow capacity: 1200 NL/min (Cv=1.3)
- Response time: ≤20ms (energize), ≤30ms (de-energize)
- Seal material: Heat-resistant NBR (-5℃ to 80℃)
- Body material: Reinforced PBT with fiberglass
- Protection class: IP67 (dust/water resistant)
- Weight: 450g ±5%
- Dimensions: 98mm(L) × 45mm(W) × 65mm(H)
- Port thread depth: 12mm
- Power consumption: 2.2W (DC24V), 4.5VA (AC)
- Ambient temperature: -5℃ to 60℃ (non-freezing)
High-flow directional control valve with dual coil operation, engineered for precision bi-directional actuator control in industrial automation. Features optimized flow paths for reduced pressure drop and rapid cycling capabilities (up to 5Hz). Includes manual override and position indicator. Requires 5μm filtered lubricated air (ISO 8573-1 class 4).
- Pneumatic cylinder sequencing in assembly lines
- Rotary actuator control for material handling systems
- Clamping/unclamping mechanisms in CNC machinery
- Packaging machine diverters and pusher arms
- Automated test equipment with dual-action requirements
Installation guidelines:
Mount horizontally with coil axis vertical. Maintain minimum 15mm
clearance below valve for exhaust airflow. Use flexible tubing
connections to prevent mechanical stress. Apply thread sealant
only on male ports (tapered threads).
| Property | Property Value |
|---|---|
| sku | 6V0520J04B200 |
| Port Size | PT 1/2 |
| Standard Voltage | DC24V |
