Airtac 6V Solenoid Valve 6V0520J04C050
2、Internal venting structure collects pilot air for centralized exhaust through R/S ports;
3、High-pressure die-cast aluminum alloy body features precision-machined inner bore for optimized flow path geometry and enhanced flow capacity;
4、Available in threaded and quick-insertion port types, compatible with base-mounted valve manifolds for space-efficient installation.
Category: Solenoid Valves | Brand: AIRTC | Series: 6V
AirTAC 6V0520J04C05 Solenoid Valve Specifications
- Model: 6V0520J04C050
- Type: 5/2-way single solenoid (spring return)
- Port size: PT1/8 (G1/8 optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage options: DC24V (±10%), AC110V/50-60Hz, AC220V/50-60Hz
- Weight: 300g ±5% (including coil)
- Dimensions: 72mm(L) × 32mm(W) × 70mm(H)
- Seal material: HNBR rubber (oil & heat resistant)
- Temperature range: -10℃ to 80℃ (non-freezing conditions)
- Power consumption: 2.5W (DC) / 4.5VA (AC)
- Response time: ≤20ms (at 0.5MPa)
- Protection rating: IP67 (coil), IP40 (valve body)
- Port thread depth: 10mm (minimum engagement)
High-flow 5-port pneumatic valve with low power coil design, featuring manual override and LED status indicator. The brass main body with nickel plating ensures corrosion resistance in humid environments. Optimized for applications requiring bi-directional cylinder control with rapid cycling up to 5Hz.
- Textile machinery thread tension control systems
- Beverage canning line actuator sequencing
- Plastic injection molding machine ejectors
- Automotive tire assembly pneumatic circuits
- Semiconductor wafer handling robotics
Maintenance tip:
Use Cv value 0.13 for flow calculations. Lubricate with ISO VG32 turbine oil
if operating below 0.3MPa. Install downstream silencer (AS-01 series recommended)
for noise-sensitive environments.
| Property | Property Value |
|---|---|
| sku | 6V0520J04C050 |
| Port Size | PT 1/2 |
| Standard Voltage | AC 110V |
