Airtac 6V Solenoid Valve 6V0520J04F050
2、Internal venting structure collects pilot air for centralized exhaust through R/S ports;
3、High-pressure die-cast aluminum alloy body features precision-machined inner bore for optimized flow path geometry and enhanced flow capacity;
4、Available in threaded and quick-insertion port types, compatible with base-mounted valve manifolds for space-efficient installation.
Category: Solenoid Valves | Brand: AIRTC | Series: 6V
AirTAC 6V0520J04F050 Solenoid Valve Specifications
- Model: 6V0520J04F050
- Type: 5/2-way double solenoid operated (pilot-controlled)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.15–1.0 MPa (21.7–145 psi)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 0.68 kg ±2% (1.5 lbs)
- Dimensions: 76mm(L) × 42mm(W) × 104mm(H)
- Seal material: Heat-resistant NBR (Nitrile) for -5℃ to 80℃
- Temperature range: -5℃ to 80℃ (with dehumidified air)
- Power consumption: 2.2W (DC24V), 4.5VA (AC220V)
- Protection rating: IP67 (dustproof and waterproof)
- Response time: ≤15ms (at 0.5MPa)
- Flow coefficient (Cv): 1.8
- Port thread depth: 12mm (minimum engagement)
- Manual override: Built-in push-button operator
High-flow bistable solenoid valve with dual coil design for energy-saving operation. Features stainless steel plunger and reinforced PBT coil housing for industrial durability. Includes LED status indicator and surge protection circuitry. Requires ISO 8573-1:2010 Class 3 compressed air (max 5mg/m³ oil content).
- Automated assembly line clamping systems
- Plastic injection molding machine actuators
- CNC tool changers and spindle brakes
- Food processing pneumatic circuits (non-contact areas)
- Electric vehicle battery pack cooling systems
Installation guidelines:
Mount in vibration-free environment with ±2° level tolerance.
Use copper-free lubricants for threaded connections.
Maintain 20mm clearance above valve for coil replacement.
Perform monthly manual cycling during standby periods.
| Property | Property Value |
|---|---|
| sku | 6V0520J04F050 |
| Port Size | PT 1/2 |
| Standard Voltage | DC12V |
