Airtac 6V Solenoid Valve 6V0520J04F200
2、Internal venting structure collects pilot air for centralized exhaust through R/S ports;
3、High-pressure die-cast aluminum alloy body features precision-machined inner bore for optimized flow path geometry and enhanced flow capacity;
4、Available in threaded and quick-insertion port types, compatible with base-mounted valve manifolds for space-efficient installation.
Category: Solenoid Valves | Brand: AIRTC | Series: 6V
AirTAC 6V0520J04F200 Solenoid Valve Specifications
- Model: 6V0520J04F200
- Type: 5/2-way double solenoid pilot-operated
- Port size: PT1/4 (G1/8 optional)
- Operating pressure: 0.1–0.9 MPa
- Max flow rate: 1200 L/min (ANR)
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil insulation class: Class F (155℃)
- Weight: 320g ±5%
- Dimensions: 80mm(L) × 45mm(W) × 75mm(H)
- Seal material: FKM (Fluoroelastomer) standard (NBR optional)
- Temperature range: -5℃ to 80℃ (non-freezing)
- Power consumption: 3.5W (DC), 4.8VA (AC)
- Response time: ≤30ms (exhaust to port A)
- Protection rating: IP67 (coil), IP40 (valve body)
- Port thread depth: 12mm (minimum engagement)
High-flow bistable solenoid valve with dual-coil latching design, engineered for precision directional control in demanding industrial environments. Features low-hysteresis operation and manual override capability. The hardened aluminum body with nickel plating ensures corrosion resistance in humid conditions. Requires 5μm filtered/dried compressed air with lubrication (ISO 8573-1 class 3-4-3).
- Plastic injection molding machine clamp systems
- Automated assembly line positioning actuators
- Textile machinery pneumatic circuits
- Semiconductor handling equipment
- Die-casting machine ejection mechanisms
Installation note:
Mount with vibration-damping brackets in high-shock environments.
Maintain 0.5-1.0mm gap between coils during dual-unit installations.
Always install downstream pressure regulator with 1.5x safety factor.
| Property | Property Value |
|---|---|
| sku | 6V0520J04F200 |
| Port Size | PT 1/2 |
| Standard Voltage | DC12V |
