Airtac 6V Solenoid Valve 6V0520M5A050
2、Internal venting structure collects pilot air for centralized exhaust through R/S ports;
3、High-pressure die-cast aluminum alloy body features precision-machined inner bore for optimized flow path geometry and enhanced flow capacity;
4、Available in threaded and quick-insertion port types, compatible with base-mounted valve manifolds for space-efficient installation.
Category: Solenoid Valves | Brand: AIRTC | Series: 6V
AirTAC 6V0520M5A050 Solenoid Valve Specifications
- Model: 6V0520M5A050
- Type: 5/2-way single solenoid spring return
- Port size: M5 (ISO 228 G1/8 equivalent)
- Operating pressure: 0.1–1.0 MPa
- Voltage: DC24V (±10%)
- Power consumption: 1.2W (0.05A @24VDC)
- Response time: ≤15ms (at 0.5MPa)
- Flow coefficient (Cv): 0.25
- Seal material: NBR (Nitrile rubber)
- Body material: PA66 reinforced nylon
- Temperature range: -5℃ to 80℃
- Protection rating: IP67 (dust/water resistant)
- Weight: 215g ±5g
- Dimensions: 54mm(L) × 36mm(W) × 65mm(H)
- Port thread depth: 9mm (recommended engagement)
High-speed 5-port pneumatic valve with energy-efficient design, featuring aluminum alloy solenoid housing for improved heat dissipation. The low-friction spool structure enables 10 million cycle durability under rated conditions. Includes manual override button for system debugging. Requires 5-40μm filtered compressed air with lubricant-free or ISO VG32 turbine oil mist lubrication.
- Factory automation cylinder control systems
- Textile machinery double-acting actuators
- Semiconductor wafer handling equipment
- Automotive assembly line clamping devices
- Bottle cap sorting machines
Installation guidelines:
Mount with DIN rail clip (optional accessory). Maintain ambient temperature below 60℃.
For horizontal mounting, orient exhaust ports downward to prevent dust ingress.
Recommended maintenance: 6-month cycle for seal inspection in continuous operation.
| Property | Property Value |
|---|---|
| sku | 6V0520M5A050 |
| Port Size | M5 |
| Standard Voltage | AC220V |
