Airtac 6V Solenoid Valve 6V0520M5A200
$44.16
Regular price
$51.66
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
6V0520M5A200
Product type:
Tags:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Plug-in electrical connection with interchangeable horizontal/vertical terminal orientation;
2、Internal venting structure collects pilot air for centralized exhaust through R/S ports;
3、High-pressure die-cast aluminum alloy body features precision-machined inner bore for optimized flow path geometry and enhanced flow capacity;
4、Available in threaded and quick-insertion port types, compatible with base-mounted valve manifolds for space-efficient installation.
Category: Solenoid Valves | Brand: AIRTC | Series: 6V
Installation requirements:
Requires 5μm filtration (40μm for emergency use). Lubricated air (ISO VG32)
recommended for high-cycle applications. Mount with vibration-damping
brackets if ambient vibration exceeds 5G. Minimum 2x port diameter
straight piping recommended upstream.
2、Internal venting structure collects pilot air for centralized exhaust through R/S ports;
3、High-pressure die-cast aluminum alloy body features precision-machined inner bore for optimized flow path geometry and enhanced flow capacity;
4、Available in threaded and quick-insertion port types, compatible with base-mounted valve manifolds for space-efficient installation.
Category: Solenoid Valves | Brand: AIRTC | Series: 6V
AirTAC 6V0520M5A200 Solenoid Valve Technical Details
- Full model number: 6V0520M5A200 (M5 coil connector variant)
- Valve type: 5/2-way direct-acting (monostable)
- Port configuration: G1/8 (ISO228/1 standard)
- Operating pressure range: 0.15–1.0 MPa (21.7–145 PSI)
- Voltage variants: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow capacity: 750 l/min (ANR) at 0.5 MPa
- Response time: ≤15ms (excitation), ≤20ms (de-excitation)
- Seal materials: HNBR main seals with FKM backup rings
- Ambient temperature: -5℃ to 60℃ (with 0℃ anti-freeze measures)
- Duty cycle: 100% continuous operation rated
- Weight: 0.38 kg ±5% (including coil assembly)
- Dimensions: 56mm(W) × 55mm(H) × 92mm(D)
- Electrical protection: Class F insulation, IP67 rated
- Port thread depth: 12mm (minimum engagement required)
High-flow directional control valve with metal piston construction for industrial automation. Features manual override button for system debugging and optimized flow paths reducing pressure drop by 18% compared to previous generation. Compatible with ISO 15407-1 standards.
Industrial Applications:
- Pneumatic cylinder sequencing in assembly lines
- Clamping fixture control for CNC machining centers
- Vacuum cup actuator systems in material handling
- Plastic injection molding machine air circuits
- Automotive tire assembly pneumatic controls
Installation requirements:
Requires 5μm filtration (40μm for emergency use). Lubricated air (ISO VG32)
recommended for high-cycle applications. Mount with vibration-damping
brackets if ambient vibration exceeds 5G. Minimum 2x port diameter
straight piping recommended upstream.
| Property | Property Value |
|---|---|
| sku | 6V0520M5A200 |
| Port Size | M5 |
| Standard Voltage | AC220V |
