Airtac 6V Solenoid Valve 6V0520M5B050
2、Internal venting structure collects pilot air for centralized exhaust through R/S ports;
3、High-pressure die-cast aluminum alloy body features precision-machined inner bore for optimized flow path geometry and enhanced flow capacity;
4、Available in threaded and quick-insertion port types, compatible with base-mounted valve manifolds for space-efficient installation.
Category: Solenoid Valves | Brand: AIRTC | Series: 6V
AirTAC 6V0520M5B050 Solenoid Valve Specifications
- Model: 6V0520M5B050
- Type: 5/2-way mono-stable (spring return)
- Port size: PT3/8 (G3/8 optional)
- Operating pressure: 0.1–1.0 MPa
- Voltage options: DC24V (±10%), AC110V/50-60Hz, AC220V/50-60Hz
- Weight: 320g ±5%
- Dimensions: 80mm(L) × 32mm(W) × 76mm(H)
- Flow coefficient (Cv): 1.8
- Seal material: Heat-resistant NBR (Nitrile Butadiene Rubber)
- Temperature range: -20℃ to 80℃ (non-freezing)
- Power consumption: 2.2W (DC24V), 4.5VA (AC)
- Response time: ≤15ms (at 0.5MPa)
- Protection rating: IP67 (dust/water resistant)
- Port thread depth: 12mm (minimum engagement)
High-flow directional control valve with double electrical interlocks, featuring brass body construction with hard-anodized aluminum core. Designed for precision bi-directional actuation in high-cycle applications. Includes manual override and surge suppression circuitry. Requires ISO 8573-1 class 3 compressed air (max 50mg/m³ oil content).
- Automated production line clamping systems
- Plastic injection molding machine ejectors
- CNC tool changers and spindle brakes
- Beverage filling station cylinder control
- Textile machinery tensioning mechanisms
Installation note:
Mount in vibration-free environment using M5 mounting screws (max torque 1.2N·m).
Maintain 15mm clearance below valve for manifold heat dissipation. Lubricate with ISO VG32
turbine oil if used in continuous operation above 60℃.
| Property | Property Value |
|---|---|
| sku | 6V0520M5B050 |
| Port Size | M5 |
| Standard Voltage | DC24V |
