Airtac 6V Solenoid Valve 6V0520M5B200
2、Internal venting structure collects pilot air for centralized exhaust through R/S ports;
3、High-pressure die-cast aluminum alloy body features precision-machined inner bore for optimized flow path geometry and enhanced flow capacity;
4、Available in threaded and quick-insertion port types, compatible with base-mounted valve manifolds for space-efficient installation.
Category: Solenoid Valves | Brand: AIRTC | Series: 6V
AirTAC 6V0520M5B200 Solenoid Valve Technical Profile
- Model: 6V0520M5B200
- Type: 5-port, 2-position (5/2-way) double solenoid operated
- Port size: PT1/4 (G1/4 equivalent)
- Thread standard: ISO 228 (BSPP)
- Operating pressure range: 0.1–1.0 MPa
- Proof pressure: 1.5 MPa
- Voltage variants: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil insulation class: Class F (155℃)
- Flow capacity (Cv value): 2.5
- Response time: ≤20ms (excitation), ≤30ms (de-excitation)
- Seal material: HNBR (Hydrogenated Nitrile) for enhanced oil resistance
- Ambient temperature range: -5℃ to 60℃ (with anti-freeze measures below 0℃)
- Protection rating: IP67 (dust tight & protected against temporary immersion)
- Weight: 650g ±5% (including coil)
- Dimensions: 130mm(L) × 52mm(W) × 68mm(H) (manifold surface to top of coil)
- Manual override: Optional paddle-type override available
- Mounting style: ISO 5599-1 compliant sub-base mounting
High-flow directional control valve with dual solenoid operation, engineered for demanding industrial automation sequences. Features corrosion-resistant aluminum alloy body with hard anodized treatment, compatible with ISO VG32 hydraulic oil mist lubrication. Requires 25μm filtration with maximum 5ppm contamination level. Compatible with vacuum applications when paired with AirTAC V-series accessories.
- Pneumatic press clamping systems in automotive manufacturing
- Multi-axis robotic arm end effectors
- Plastic injection molding machine ejectors
- High-cycle packaging line diverters
- CNC machine tool chuck actuators
Installation guidelines:
Use anti-vibration washers when mounting on mobile platforms.
Maintain 20mm clearance above coil for heat dissipation.
Lubricate seals with PPSO-1 grease during maintenance.
| Property | Property Value |
|---|---|
| sku | 6V0520M5B200 |
| Port Size | M5 |
| Standard Voltage | DC24V |
