Airtac 6V Solenoid Valve 6V0520M5C050
$41.84
Regular price
$49.34
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
6V0520M5C050
Product type:
Tags:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Plug-in electrical connection with interchangeable horizontal/vertical terminal orientation;
2、Internal venting structure collects pilot air for centralized exhaust through R/S ports;
3、High-pressure die-cast aluminum alloy body features precision-machined inner bore for optimized flow path geometry and enhanced flow capacity;
4、Available in threaded and quick-insertion port types, compatible with base-mounted valve manifolds for space-efficient installation.
Category: Solenoid Valves | Brand: AIRTC | Series: 6V
Installation guidelines:
2、Internal venting structure collects pilot air for centralized exhaust through R/S ports;
3、High-pressure die-cast aluminum alloy body features precision-machined inner bore for optimized flow path geometry and enhanced flow capacity;
4、Available in threaded and quick-insertion port types, compatible with base-mounted valve manifolds for space-efficient installation.
Category: Solenoid Valves | Brand: AIRTC | Series: 6V
AirTAC 6V0520M5C050 Solenoid Valve Technical Details
- Model: 6V0520M5C050
- Type: 5/2-way single solenoid valve (spring return)
- Port size: PT1/8 (G1/8 optional)
- Operating pressure: 0.1–0.8 MPa (14.5–116 PSI)
- Voltage options: DC24V (±10%) / AC110V (50/60Hz) / AC220V (50/60Hz)
- Flow capacity: 650 l/min (Cv=1.0)
- Fluid medium: Compressed air (lubricated or non-lubricated)
- Temperature range: -20℃ to 80℃ (non-freezing)
- Response time: ≤15ms (energized), ≤20ms (de-energized)
- Protection rating: IP67 (dust/water resistant)
- Seal material: Heat-resistant NBR
- Weight: 210g ±5% (without connectors)
- Dimensions: 52mm(L) × 34mm(W) × 75mm(H)
- Mounting type: Sub-base or direct piping (M5 thread)
High-flow 5-port directional control valve with manual override, featuring dual-color LED status indicator. The hardened stainless steel plunger and corrosion-resistant PPS coil housing ensure 10 million+ cycle durability. Compatible with ISO 15407-1 standards.
Industrial Applications:
- Double-acting cylinder control in automation lines
- Pneumatic clamping systems for CNC machines
- Material handling equipment (conveyors, sorters)
- Textile machinery tension control
- Bottle cap tightening systems
Installation guidelines:
- Allow ≥20mm clearance below valve for manual override access
- Use vibration-damping mounts if operating frequency exceeds 5Hz
- Install downstream air filter (≤5μm) for optimal performance
- For vertical mounting, ensure exhaust ports face downward
| Property | Property Value |
|---|---|
| sku | 6V0520M5C050 |
| Port Size | M5 |
| Standard Voltage | AC 110V |
