Airtac AirTAC P-4V Repair Kit P-4V420-R1
AirTAC P-4V420-R1 Repair Kit Technical Details
- Model: P-4V420-R1
- Compatible with: P-4V420 series pneumatic valves
- Components included:
- Nitrogen-filled NBR main seals (x2)
- PTFE-coated piston rings (x2)
- Spring-loaded valve stem seals (x4)
- Dust-proof U-cup seals (x2)
- Stainless steel compression springs (x2)
- Anti-extrusion washers (x4)
- Material composition: 70% HNBR / 30% FKM compound
- Temperature tolerance: -25℃ to +120℃ (continuous)
- Pressure rating: 0.1–1.0 MPa
- Weight: 118g ±2g (including packaging)
- Dimensions: 85mm(L) × 45mm(W) × 25mm(H)
- Storage humidity: ≤75% RH (non-condensing)
- Shelf life: 5 years in original sealed packaging
Comprehensive maintenance solution for high-cycle pneumatic valves, featuring abrasion-resistant seals with 30% improved service life compared to standard kits. Precision-engineered components maintain original valve tolerances within ±0.01mm during rebuilds. Includes anti-static treated seals for explosive atmosphere compliance.
- Preventive maintenance in automated assembly lines
- Post-contamination flush procedures in foundry equipment
- High-frequency valve refurbishment for packaging machinery
- Emergency repair kits for automotive paint shop pneumatics
- FDA-compliant seal replacement in food processing systems
Installation protocol:
Always degrease components with isopropyl alcohol before assembly.
Apply silicone-free lubricant (ISO VG32 equivalent) to sliding surfaces.
Torque housing bolts in cross pattern to 1.2N·m ±0.1N·m.
| Property | Property Value |
|---|---|
| sku | P-4V420-R1 |
