Airtac B52-F-RMS Axial Mounting Bracket Finished Assembly Kit B52-F-RMS20LB
AirTAC B52-F-RMS20LB Axial Fixation Kit Complete Set
- Full Model: B52-F-RMS20LB
- Type: Linear motion axial support unit
- Material: Aluminum alloy body + steel reinforcement
- Inner diameter: Ø20mm (precisely 20.0±0.1mm)
- Outer diameter: Ø42mm (flange contact surface)
- Mounting holes: 4×M5 threaded (6mm hole spacing)
- Radial load capacity: 1,200N static / 800N dynamic
- Axial load capacity: 2,500N
- Operating temperature: -20℃ to 80℃ (continuous)
- Surface treatment: Nickel-plated (3-5μm thickness)
- Seal material: NBR rubber (oil-resistant grade)
- Protection rating: IP54 (dust/water resistant)
- Weight: 350g ±5% (including all hardware)
- Dimensions: 50mm(L) × 30mm(W) × 25mm(H)
Precision-engineered axial stabilization solution for pneumatic cylinders, featuring dual-row ball bearing design that reduces 89% of radial play compared to standard bushings. The self-lubricating guide structure ensures smooth linear motion while preventing axis deflection in high-moment applications. Includes mounting screws, alignment shims (0.1/0.2/0.5mm), and anti-vibration washers.
- High-speed pick-and-place robot end effectors
- CNC machine tool cylinder stabilization
- Packaging machinery vertical lift guides
- Automated welding equipment actuator support
- Semiconductor handling vacuum cylinder alignment
Installation protocol:
Apply 2-3Nm torque during M5 screw fastening. Use included 0.2mm shim
when axial clearance exceeds 0.05mm. Relubricate every 50km of travel
using ISO VG32 hydraulic oil.
| Property | Property Value |
|---|---|
| sku | B52-F-RMS20LB |
