Airtac F-ACA-FA Flange Mounting Plate Complete Kit F-ACA36FA
AirTAC F-ACA-FA Flange Mounting Kit F-ACA36FA Technical Details
- Model: F-ACA36FA (Complete Kit)
- Compatible cylinder series: F-AFC36/M-AFC36
- Material: Aluminum alloy ADC12
- Surface treatment: Anodized (natural color)
- Mounting hole pattern: 36mm × 36mm square
- Bolt holes: 4×M6 threaded (depth 10mm)
- Base thickness: 12mm ±0.2
- Weight: 0.54kg ±3%
- Dimensions: 100mm(L) × 80mm(W) × 20mm(H)
- Load capacity: Max 200N lateral force
- Temperature range: -20℃ to 80℃
- Mounting torque: 4.9-6.9N·m (M6 bolts)
- Accessories included: 4×M6×16 hex socket screws, 4×Φ6.5mm washers
Precision-machined mounting solution for cylinder stabilization, featuring anti-vibration design with reinforced rib structure. The pre-assembled kit includes corrosion-resistant hardware for immediate installation. Optimized for shock absorption in high-cycle applications (up to 1.5 million cycles).
- Industrial robot end-effector mounting
- Packaging machine vertical cylinder support
- Conveyor system pusher mechanisms
- Automated welding fixture bases
- CNC machine tool pneumatic clamping
Installation protocol:
Apply medium-strength thread locker (LOCTITE 243 recommended) on bolts.
Use 0.1mm precision shims for base alignment. Torque in cross pattern
sequence. Re-tighten after 50 operational cycles.
| Property | Property Value |
|---|---|
| sku | F-ACA36FA |
| Internal Thread Specification | M36x1.5 |
