Airtac F-ACA-FA Flange Mounting Plate Complete Kit F-ACA42FA
AirTAC F-ACA-FA Flange Mounting Plate Complete Kit (F-ACA42FA)
- Model: F-ACA42FA
- Type: Pre-assembled flange mounting plate kit
- Material: Aluminum alloy (anodized surface treatment)
- Compatible Cylinder Series: ACA32~ACA100
- Mounting Hole Pattern: 30mm × 30mm grid (M6 threaded holes)
- Base Plate Thickness: 8mm ±0.1mm
- Surface Hardness: HV 120±15
- Weight: 0.65kg ±3%
- Dimensions: 120mm(L) × 42mm(W) × 42mm(H)
- Operating Temperature: -20℃ to 80℃
- Corrosion Resistance: 96hr salt spray test compliant
- Mounting Torque: 5.4N·m max (for M6 fasteners)
- Vibration Resistance: 10-55Hz, 1.5mm amplitude
Precision-machined mounting solution designed for stable fixation of AirTAC ACA series cylinders. Features diamond-knurled grip surfaces for anti-slip alignment and four reinforced mounting ears with stress-relief design. Includes pre-installed mounting hardware with Loctite® threadlocker treatment.
- Robotic arm joint articulation systems
- High-cycle packaging line actuators
- Food processing equipment (NSF-compliant surface)
- Cleanroom automation with frequent component swaps
- Vibration-intensive conveyor systems
Installation protocol:
Use M6×25mm grade 8.8 bolts with spring washers.
Apply 3-stage torque sequence (30% → 60% → 100% of max torque)
in cross pattern. Verify perpendicularity with 0.05mm/m tolerance.
| Property | Property Value |
|---|---|
| sku | F-ACA42FA |
| Internal Thread Specification | M42 |
