Airtac F-ACQ-I Connector Assembly Kit F-ACQ100I
AirTAC F-ACQ-I Series Quick Connector Kit (F-ACQ100I) Technical Details
- Model Code: F-ACQ100I
- Series: F-ACQ-I Push-to-Connect Fittings
- Body Material: Nickel-plated brass (corrosion resistant)
- Thread Standard: PT1/8 (BSPP) female thread
- Tube Compatibility: 6mm OD pneumatic tubing (PU/Nylon)
- Max Working Pressure: 1.5 MPa (217 psi)
- Pressure Range: 0.05-1.5 MPa
- Temperature Range: -20℃ to 80℃ (-4°F to 176°F)
- Seal Material: HNBR (Hydrogenated Nitrile) for chemical resistance
- Flow Rate: 450 NL/min @ 0.5 MPa
- Leakage: ≤0.1 Nml/min @ 0.5 MPa (ISO 6952 compliant)
- Weight: 150g ±5% (including packaging)
- Dimensions: 60mm(L) × 25mm(W) × 25mm(H)
- Package Contents: 10 pcs connectors + 20 O-rings + installation tool
- Certifications: RoHS compliant, ISO 6150-1 pneumatic standard
Industrial-grade quick-disconnect fittings designed for rapid assembly in pneumatic systems. Features 360° rotatable collar for flexible tube positioning and a positive-lock mechanism that audibly clicks when fully engaged. The nickel plating provides enhanced surface hardness (500-600HV) and salt spray resistance exceeding 96 hours.
- Step 1: Cut tube square using tube cutter
- Step 2: Insert tube until it bottoms out (6mm insertion depth)
- Step 3: Pull back gently to confirm secure connection
- Primary Use: Compressed air lines in factory automation
- Vacuum Systems: Compatible down to -100kPa
- Medical Gas: Optional cleanroom-packaged version available
- Robotics: Vibration-resistant design for moving arms
Maintenance Tip:
Replace O-rings every 50,000 cycles or 2 years (whichever comes first).
Use silicone grease (AS-9301 spec) for lubrication. Avoid side-load forces exceeding 15N.
Critical Note:
Not compatible with PTFE tubes or aggressive chemicals like chlorinated solvents.
Maximum permissible momentary pressure spike: 2.25 MPa.
