Airtac F-ACQ-Y Fitting Assembly F-ACQ16Y
AirTAC F-ACQ-Y Fitting Kit F-ACQ16Y Technical Details
- Model: F-ACQ16Y (Complete Fitting Kit)
- Series: ACQ-Y Push-in Fittings
- Thread Standard: M5×0.8 (Metric Fine)
- Material: PA66+GF25% (Nylon 66 with 25% Glass Fiber)
- Seal Material: HNBR (Hydrogenated Nitrile Rubber)
- Operating Pressure: 0.05-1.0 MPa
- Temperature Range: -20℃ to +80℃
- Tube Compatibility: Ø4mm (OD) Polyurethane/Nylon Tubing
- Vibration Resistance: ≤4.9m/s²
- Weight: 22g ±0.5g (per complete fitting)
- Dimensions: 28mm(L) × 18mm(W) × 16mm(H) (Body Only)
- Installation Torque: 0.7-1.2N·m
- IP Rating: IP40 (Protected against solid objects over 1mm)
- Certification: RoHS 2011/65/EU Compliant
High-density push-to-connect pneumatic fitting with integrated collar lock mechanism, designed for leak-proof connections in compact pneumatic systems. Features 360° rotatable port orientation and automatic tube grip reinforcement under pressure. Includes built-in dust cap and O-ring pre-lubricated with silicone grease.
- Modular pneumatic circuit assembly in robotics
- Multi-axis CNC machine tool air supply networks
- Laboratory analytical instrument gas lines
- Food packaging machine actuator connections
- Semiconductor manufacturing cleanroom systems
Installation Guidelines:
Cut tubing ends square (90°±2°) using dedicated cutter. Insert until tactile "click" is heard.
For disassembly: Pull back blue collar fully before tube removal. Max reusability: 50 cycles.
Compatibility Note:
Not suitable for phosphate ester-based hydraulic fluids or ketone solvents.
Requires annual O-ring replacement in continuous 24/7 operation.
| Property | Property Value |
|---|---|
| sku | F-ACQ16Y |
| Bore Diameter | 16mm |
