Airtac F-ACQ-Y Fitting Assembly F-ACQ32Y
$12.78
Regular price
$20.28
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
F-ACQ32Y
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
Category: Cylinder Y-Connector Assembly
Brand: AIRTAC
Series: F-ACQ-Y
Professional-grade pneumatic Y-type connector assembly designed for efficient flow distribution in cylinder port configurations. Engineered with precision-machined brass/nickel-plated components to ensure leak-free performance and corrosion resistance. Features standardized thread specifications (G/Metric) for seamless integration with AIRTAC cylinder series and industrial pneumatic systems. Optimized internal flow design minimizes pressure loss while maintaining consistent bidirectional operation. Includes pre-assembled fittings and O-rings compliant with ISO 6431/6432 standards. Ideal for compact piping layouts requiring branch circuit connections in automation equipment.
Installation guidelines:
Apply 15-20N·m torque during threading. Lubricate O-rings with silicone grease (P/N: AG-08) before initial use.
Maximum angular misalignment tolerance: 3°.
AirTAC F-ACQ-Y Series Quick Coupling Assembly F-ACQ32Y Specifications
- Model: F-ACQ32Y
- Series: F-ACQ-Y (Threaded connector with check valve)
- Thread Standard: G1/8 (ISO 228-1 compliant)
- Material: Nickel-plated brass body, NBR seals
- Applicable Tube OD: Φ12mm (with 12x18mm compression range)
- Max Working Pressure: 1.5 MPa (15 bar)
- Temperature Range: -20℃ to +80℃
- Flow Rate: 2,800 Nl/min (Cv=4.8)
- Sealing Method: Double O-ring structure
- Vibration Resistance: ≤1.5mm amplitude at 10-55Hz
- Weight: 148g ±2g
- Dimensions: 62mm(L) × 34mm(W) × 28mm(H)
- IP Rating: IP54 (dust protected, water splashed)
- Certification: RoHS compliant, ISO 14743 standard
Premium push-to-connect coupling with integrated check valve for instant flow shutoff during disconnection. Features 360° rotatable nipple and anti-dust cap retention system. The Y-series variant includes an automatic shutoff mechanism preventing air leakage when disconnected.
Typical Applications:
- Pneumatic tool quick-change systems
- Automated assembly line air circuits
- Medical gas equipment connections
- Packaging machine air supply interfaces
- Robotic arm end-effector tooling
Installation guidelines:
Apply 15-20N·m torque during threading. Lubricate O-rings with silicone grease (P/N: AG-08) before initial use.
Maximum angular misalignment tolerance: 3°.
| Property | Property Value |
|---|---|
| sku | F-ACQ32Y |
| Bore Diameter | <32 mm> |
