Airtac F-DSUB Cable F-DSUB25S150
Category: Solenoid Valve Coils | Brand: AirTAC | Series: F-DSUB
AirTAC F-DSUB25S150 D-Sub Cable Assembly Specifications
- Model: F-DSUB25S150
- Connector type: D-Subminiature 25-pin (DB25)
- Gender configuration: Male to female (standard)
- Cable length: 150mm ±2%
- Wire gauge: 28AWG twisted pair
- Shielding: Dual-layer (aluminum foil + tinned copper braid)
- Insulation material: PVC (UL 1061 compliant)
- Voltage rating: 300V AC/DC max
- Current capacity: 1A per contact
- Contact resistance: ≤30mΩ
- Insulation resistance: ≥1000MΩ at 500VDC
- Temperature range: -40℃ to 105℃
- Weight: 215g ±5%
- Dimensions:
- Connector A: 45mm(W) × 15mm(H)
- Connector B: 45mm(W) × 15mm(H)
- Cable diameter: Ø6.5mm
- Certifications: RoHS, REACH, UL/cUL recognized
- Color: Steel gray (standard), custom colors available
High-density shielded cable assembly with gold-plated contacts (0.8μm thickness) for reliable signal transmission in EMI-sensitive environments. Features strain relief boots with 360° rotation capability and IP67-rated sealing when mated. Compatible with multiple protocols including RS-232, RS-422, and parallel data transmission.
- Industrial PLC communication interfaces
- CNC machine tool control systems
- Medical imaging equipment data ports
- Avionics test bench connections
- Robotic arm signal transmission
- Broadcast studio equipment interlinks
Installation guidelines:
Maintain minimum bend radius of 50mm during routing.
Use torque-controlled screwdriver (0.4-0.6Nm) for connector fastening.
Apply dielectric grease (MIL-G-81322E compliant) in high-humidity environments.
| Property | Property Value |
|---|---|
| sku | F-DSUB25S150 |
