Airtac F-DSUB Cable F-DSUB37M500
Category: Solenoid Valve Coils | Brand: AirTAC | Series: F-DSUB
AirTAC F-DSUB37M500 Industrial Signal Cable Specifications
- Model: F-DSUB37M500
- Type: D-SUB 37-pin male-to-male signal transmission cable
- Connector Type: High-density D-SUB 37-pin (DB37) with nickel-plated shell
- Cable Length: 500mm ±10mm (custom lengths available)
- Conductor: 28 AWG tinned copper (7/0.127mm strands per core)
- Shielding: Dual-layer protection - aluminum foil + 85% coverage tinned copper braid
- Insulation: PVC compound (0.8mm thickness)
- Jacket: Oil-resistant PUR (polyurethane) outer sheath, Ø8mm
- Voltage Rating: 300V AC/DC max
- Temperature Range: -40℃ to 80℃ (flexing), -25℃ to 80℃ (static)
- Bend Radius: 8× cable diameter minimum
- Certification: CE, RoHS, UL/cUL AWM 20276 80℃ 300V
- Contact Resistance: ≤30mΩ
- Insulation Resistance: ≥100MΩ/km
- Weight: 480g ±5% (including connectors)
- Dimensions:
- Connector A: 50mm(L) × 20mm(W) × 15mm(H)
- Connector B: 50mm(L) × 20mm(W) × 15mm(H)
- Cable Diameter: 8mm
High-reliability shielded cable assembly designed for precision signal transmission in industrial automation systems. Features gold-plated contacts (1.5μm thickness) for stable conductivity and corrosion resistance. The double-shielded design with 360° grounding ensures EMI/RFI protection in high-noise environments. PUR jacket provides excellent resistance to oils, coolants, and abrasion.
- CNC machine tool I/O connections
- Robotic arm control signal transmission
- PLC-to-HMI communication interfaces
- Industrial vision system cabling
- Test & measurement equipment links
Installation guidelines:
Maintain minimum 50mm separation from power cables. Use strain relief clamps within 100mm of connectors.
For optimal EMI protection, ground both connector shells to chassis earth using star washers.
- Compatible with AirTAC ADSU37 series receptacles
- Matches standard DB37 pin configurations
- Works with 1.6-2.0mm panel cutouts
| Property | Property Value |
|---|---|
| sku | F-DSUB37M500 |
