Airtac F-GF Pressure Gauge F-GF4004B
2、Clear dial markings with selectable pressure units (PSI, bar, kPa, MPa);
3、Versatile mounting configurations and compatible accessories available;
4、Multiple port sizes (1/8", 1/4", 3/8") for flexible pipeline integration.
Category: Pressure Gauges , Brand: AIRTAC , Series: F-GF
AirTAC F-GF4004B Pressure Gauge Technical Details
- Model: F-GF4004B
- Type: Bourdon tube pressure gauge with glycerin filling
- Pressure range: 0-1.6 MPa (0-232 PSI) standard (custom ranges available)
- Accuracy: ±1.6% of full scale (ASME B40.100 Grade B)
- Connection: 1/4" NPT male thread (BSPP optional)
- Dial size: 63mm diameter
- Case material: 304 stainless steel with polycarbonate window
- Weight: 300g ±5% (with glycerin fill)
- Dimensions: 63mm(D) × 65mm(H) (body only)
- Mounting depth: 50mm from back flange
- Temperature range: -20℃ to 60℃ (operating fluid)
- Vibration resistance: Up to 25Hz/2mm amplitude
- Protection rating: IP54 (front face)
- Fill fluid: Glycerin (98% purity, frost-resistant variant optional)
Industrial-grade pressure measurement instrument featuring shock-absorbing liquid fill and corrosion-resistant construction. The 270° scale rotation allows flexible mounting orientations. Dual-scale display (MPa & PSI) with luminous markers for low-light environments. Includes overpressure safety stop at 130% FS.
- Hydraulic power unit pressure monitoring
- Pneumatic compressor outlet pressure verification
- Plastic injection molding machine pressure feedback
- Industrial boiler auxiliary pressure indication
- CNC machine tool lubrication systems
Installation guidelines:
Use PTFE tape on threads and tighten with 14-18 N·m torque.
Maintain 10mm clearance behind gauge for shock absorption.
Avoid mounting near heat sources exceeding 80℃.
Calibrate quarterly under 75% load conditions.
| Property | Property Value |
|---|---|
| sku | F-GF4004B |
| Port Size | PT1/8 |
