Airtac F-GF Pressure Gauge F-GF4004M
2、Clear dial markings with selectable pressure units (PSI, bar, kPa, MPa);
3、Versatile mounting configurations and compatible accessories available;
4、Multiple port sizes (1/8", 1/4", 3/8") for flexible pipeline integration.
Category: Pressure Gauges , Brand: AIRTAC , Series: F-GF
AirTAC F-GF4004M Pressure Gauge Technical Details
- Model: F-GF4004M
- Type: Bourdon tube pressure gauge with mechanical movement
- Pressure range: 0-1.6 MPa (0-232 psi)
- Accuracy: ±2% F.S. (Full Scale)
- Connection type: G1/4" male thread (BSPP standard)
- Dial diameter: 63mm (2.5")
- Case material: Stainless steel SS304 housing
- Window material: Polycarbonate (impact-resistant)
- Movement lubrication: Silicon-free
- Weight: 300g ±5%
- Dimensions: 80mm (W) × 80mm (H) × 30mm (D)
- Mounting depth: 15mm panel cutout
- Temperature range: -20℃ to 60℃ (operating fluid)
- Protection rating: IP54 (dust & water splash resistant)
- Overpressure safety: 130% F.S. burst protection
Industrial-grade pressure measurement instrument with shock-resistant construction and clear 270° scale visibility. Features a dry movement design eliminating fluid contamination risks. Calibration adjustment via rear hex key port. Compatible with air, non-flammable gases, and hydraulic fluids (non-corrosive media).
- Pneumatic system pressure monitoring in CNC machines
- Hydraulic power unit pressure verification
- Compressed air line diagnostics in automotive workshops
- Process control in plastic injection molding equipment
- Energy management systems for industrial chillers
Installation guidelines:
Mount vertically with connection port downward to prevent media pooling.
Use 5mm thick rubber washer (included) for vibration damping.
Avoid installation near heat sources exceeding 80℃ ambient temperature.
| Property | Property Value |
|---|---|
| sku | F-GF4004M |
| Port Size | PT1/8 |
