Airtac F-GF Pressure Gauge F-GF4004Z
2、Clear dial markings with selectable pressure units (PSI, bar, kPa, MPa);
3、Versatile mounting configurations and compatible accessories available;
4、Multiple port sizes (1/8", 1/4", 3/8") for flexible pipeline integration.
Category: Pressure Gauges , Brand: AIRTAC , Series: F-GF
AirTAC F-GF4004Z Pressure Gauge Technical Specifications
- Model: F-GF4004Z
- Type: Bourdon tube pressure gauge (mechanical)
- Pressure range: 0-1.6 MPa (0-16 bar / 0-232 psi)
- Connection size: G1/4" female thread (NPT1/4" optional)
- Accuracy class: ±2.5% full scale (EN 837-1 standard)
- Case material: Stainless steel SS304
- Window material: Polycarbonate (impact-resistant)
- Dial diameter: 60mm (2.36")
- Temperature limits:
- Ambient: -20℃ to +70℃
- Media: -20℃ to +80℃ (with NBR seal)
- Protection rating: IP40 (front face)
- Mounting orientation: Radial (bottom entry)
- Weight: 250g ±5% (without packaging)
- Dimensions:
- Height: 65mm (2.56") from mounting surface
- Case diameter: 60mm (2.36")
- Connection depth: 12mm (0.47")
Robust industrial pressure gauge featuring a chrome-plated brass movement mechanism and 270° scale rotation. The glycerin-filled dampening system minimizes needle vibration in pulsating environments. Calibrated for dry air and non-corrosive gases, with optional oil pulse protector (GF-OP accessory).
- Air compressor output monitoring
- Pneumatic tool pressure regulation
- Hydraulic system standby pressure indication
- Industrial boiler auxiliary pressure display
- HVAC refrigerant line monitoring
Installation guidelines:
Use PTFE tape on threads and tighten to 12-15 N·m torque. Avoid mounting in locations with direct vibration - use flexible tubing if necessary. For vertical installations exceeding 2m above eye level, specify models with 90° rotated dial.
| Property | Property Value |
|---|---|
| sku | F-GF4004Z |
| Port Size | PT1/8 |
