Airtac F-GF Pressure Gauge F-GF4010M
2、Clear dial markings with selectable pressure units (PSI, bar, kPa, MPa);
3、Versatile mounting configurations and compatible accessories available;
4、Multiple port sizes (1/8", 1/4", 3/8") for flexible pipeline integration.
Category: Pressure Gauges , Brand: AIRTAC , Series: F-GF
AirTAC F-GF4010M Pressure Gauge Technical Details
- Model: F-GF4010M
- Type: Bourdon tube pressure gauge with glycerin-filled dampening
- Pressure range: 0-1.0 MPa (customizable to 0-10MPa)
- Accuracy class: ±1.6% F.S (ASME B40.100 Grade B)
- Connection type: G1/4" BSPP female thread (NPT optional)
- Dial diameter: 40mm (1.57")
- Case material: Stainless steel SS304
- Window: Polycarbonate with shatter-resistant coating
- Liquid filling: 90% glycerin (temperature-stabilized)
- Operating temperature: -20℃ to 60℃
- Proof pressure: 1.5x full scale
- Burst pressure: 3x full scale minimum
- Weight: 320g ±5% (without packaging)
- Dimensions: 82mm(H) × 40mm(W) × 40mm(D)
- Protection rating: IP54 (splash/dust resistant)
Industrial-grade pressure measurement instrument featuring vibration-resistant construction and temperature-compensated movement. The glycerin-filled chamber minimizes pointer oscillation in pulsating systems. Calibrated for both gas and liquid media compatibility (non-corrosive fluids only).
- Hydraulic power pack pressure monitoring
- Plastic injection molding machine pressure verification
- Compressed air system diagnostics
- Pneumatic tool performance testing stations
- Industrial boiler auxiliary pressure indication
Installation guidelines:
Mount vertically with connection port downward. Use thread seal tape on male fittings.
Avoid direct sunlight exposure. Perform zero-point calibration every 2,000 operating hours.
Maximum vibration limit: 25Hz at 2g acceleration.
| Property | Property Value |
|---|---|
| sku | F-GF4010M |
| Port Size | PT1/8 |
