Airtac F-GF Pressure Gauge F-GF4010Z
$8.34
Regular price
$15.84
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
F-GF4010Z
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、High sensitivity with low-pressure activation threshold;
2、Clear dial markings with selectable pressure units (PSI, bar, kPa, MPa);
3、Versatile mounting configurations and compatible accessories available;
4、Multiple port sizes (1/8", 1/4", 3/8") for flexible pipeline integration.
Category: Pressure Gauges , Brand: AIRTAC , Series: F-GF
Installation Guidelines:
1. Mount vertically using rear 1/8" port
2. Use 2mm thick sealing washer (included)
3. Avoid torque exceeding 15N·m during installation
4. For pulsating systems, select glycerin-filled version
5. Calibrate quarterly using dead-weight tester
2、Clear dial markings with selectable pressure units (PSI, bar, kPa, MPa);
3、Versatile mounting configurations and compatible accessories available;
4、Multiple port sizes (1/8", 1/4", 3/8") for flexible pipeline integration.
Category: Pressure Gauges , Brand: AIRTAC , Series: F-GF
AirTAC F-GF4010Z Pressure Gauge Technical Specifications
- Model: F-GF4010Z (Stainless Steel Connection Version)
- Measurement Range: 0-1.0 MPa (Standard) / Customizable 0-0.6/1.6/2.5 MPa
- Connection Type: G1/8" BSPP Female Thread (NPT Optional)
- Accuracy Class: ±2.5% F.S. (Grade 2.5)
- Case Material: Black ABS with UV coating
- Dial Window: 3mm Thick Polycarbonate
- Bourdon Tube: Phosphor Bronze C1220
- Pressure Proof: 1.5x Full Scale
- Burst Pressure: ≥3x Full Scale
- Operating Temp: -20℃ to +60℃ (Dry Air)
- Vibration Resistance: ≤2.5m/s² (10-55Hz)
- Weight: 205g ±5g (Dry)
- Dimensions: Ø60mm × 70mm(H) × 100mm(L) (Incl. Connection)
- IP Rating: IP40 (Front Face IP54 when panel-mounted)
- Optional Features: Glycerin-filled (F-GF4010ZY variant) for dampening
Rugged radial-mount pressure gauge with shock-resistant movement and zero-point calibration mark. Features dual-scale bar/psi markings (0-1MPa / 0-145psi) with luminous pointer for low-light visibility. The stainless steel connection resists corrosion in humid environments.
Industrial Applications:
- Pneumatic circuit monitoring in CNC machines
- Compressed air station pressure verification
- Plastic injection molding machine pressure feedback
- Packaging line regulator performance checks
- Hydraulic test bench auxiliary measurement
Installation Guidelines:1. Mount vertically using rear 1/8" port
2. Use 2mm thick sealing washer (included)
3. Avoid torque exceeding 15N·m during installation
4. For pulsating systems, select glycerin-filled version
5. Calibrate quarterly using dead-weight tester
| Property | Property Value |
|---|---|
| sku | F-GF4010Z |
| Port Size | PT1/8 |
