Airtac F-GF Pressure Gauge F-GF5004B
2、Clear dial markings with selectable pressure units (PSI, bar, kPa, MPa);
3、Versatile mounting configurations and compatible accessories available;
4、Multiple port sizes (1/8", 1/4", 3/8") for flexible pipeline integration.
Category: Pressure Gauges , Brand: AIRTAC , Series: F-GF
AirTAC F-GF5004B Pressure Gauge Technical Details
- Model: F-GF5004B (Mechanical Bourdon Tube Type)
- Pressure Range: 0-1.0 MPa (Customizable up to 60 MPa)
- Connection: G1/4" BSPP Female Thread (NPT optional)
- Accuracy Class: ±2.5% F.S. (ASME B40.1 Grade B)
- Case Material: 304 Stainless Steel with Polycarbonate Lens
- Movement Material: Copper Alloy
- Dial Size: 50mm Diameter
- Temperature Limits:
- Ambient: -20℃ to 60℃
- Medium: Max 80℃ for continuous use
- Protection Rating: IP65 (Dust-tight & Water Jet Resistant)
- Vibration Resistance: ≤25Hz with 1.5mm amplitude
- Weight: 280g ±5% (Dry, without packaging)
- Dimensions: 72mm(H) × 50mm(Dia) × 25mm(Back Length)
Rugged industrial pressure gauge featuring shock-absorbing silicone oil filling and anti-parallax dial design. The stainless steel case withstands corrosive environments while the 270° scale rotation allows flexible mounting orientations. Includes a built-in pressure relief port (1.5× max pressure burst protection) and zero adjustment screw.
- Hydraulic power unit pressure monitoring
- Pneumatic conveyor system diagnostics
- HVAC refrigerant pressure verification
- Water treatment plant pump stations
- CNC machine lubrication systems
Installation Guidelines:
Mount using 19mm wrench flats (do not overtighten - max 35N·m torque).
For pulsating media, install snubber accessory (F-SN04 recommended).
Calibrate quarterly using 0.05-class reference gauge.
| Property | Property Value |
|---|---|
| sku | F-GF5004B |
| Port Size | PT1/4 |
