Airtac F-GF Pressure Gauge F-GF5010B
2、Clear dial markings with selectable pressure units (PSI, bar, kPa, MPa);
3、Versatile mounting configurations and compatible accessories available;
4、Multiple port sizes (1/8", 1/4", 3/8") for flexible pipeline integration.
Category: Pressure Gauges , Brand: AIRTAC , Series: F-GF
AirTAC F-GF5010B Pressure Gauge Technical Details
- Model: F-GF5010B
- Type: Bourdon tube pressure gauge with glycerin damping
- Pressure range: 0-1.0 MPa (customizable up to 10 MPa)
- Accuracy class: ±2.5% F.S (Grade 2.5)
- Connection size: G1/4" BSPP female thread
- Dial diameter: 50mm (1.97")
- Case material: Stainless steel SS304
- Window material: Polycarbonate (impact-resistant)
- Fluid temperature: -20℃ to 60℃
- Ambient temperature: -10℃ to 50℃
- Protection rating: IP54 (splash & dust resistant)
- Weight: 280g ±5% (with glycerin fill)
- Dimensions: 65mm(W) × 65mm(H) × 35mm(D)
Industrial-grade pressure measurement instrument featuring vibration-resistant construction and 270° scale visibility. The glycerin-filled chamber dampens needle oscillation in high-pulsation environments. Calibrated for both gas and liquid media compatibility (non-corrosive fluids only).
- Hydraulic power unit pressure monitoring
- Pneumatic compressor system diagnostics
- CNC machine tool fluid circuits
- Water treatment plant pump stations
- HVAC refrigerant pressure checks
Installation guidelines:
Mount vertically with connection port downward. Use PTFE tape on threads
and tighten to 12-15 N·m torque. Avoid direct sunlight exposure to prevent
glycerin discoloration. Perform zero-point calibration monthly.
| Property | Property Value |
|---|---|
| sku | F-GF5010B |
| Port Size | PT1/4 |
