Airtac F-GF Pressure Gauge F-GF5010M
2、Clear dial markings with selectable pressure units (PSI, bar, kPa, MPa);
3、Versatile mounting configurations and compatible accessories available;
4、Multiple port sizes (1/8", 1/4", 3/8") for flexible pipeline integration.
Category: Pressure Gauges , Brand: AIRTAC , Series: F-GF
AirTAC F-GF5010M Pressure Gauge Technical Details
- Model: F-GF5010M
- Type: Bourdon tube pressure gauge with mechanical display
- Measurement range: 0-1.0 MPa (customizable up to 10 MPa)
- Accuracy class: 1.6 (EN 837-1 standard)
- Connection type: G1/4" female thread (BSPP)
- Dial diameter: 60mm ±0.5mm
- Case material: Stainless steel SS304 housing
- Window material: Shatter-resistant polycarbonate
- Operating temperature: -20℃ to +60℃
- Pressure medium: Compatible with air, oil, water (non-corrosive gases/liquids)
- Protection rating: IP54 (dust and water splash resistant)
- Weight: 300g ±5% (including packaging)
- Dimensions: 60mm(D) × 65mm(H) × 35mm(installation depth)
- Scale color options: Black on white, red zone customizable
- Mounting orientation: Vertical ±5° tolerance
Rugged industrial pressure gauge featuring anti-vibration design with liquid-filled option (specify F-GF5010M/L for glycerin-filled version). The stainless steel case incorporates a blow-out safety back design complying with EN 837-3 standards. Features a 270° scale rotation capability for flexible installation alignment.
- Industrial air compressor pressure monitoring
- Pneumatic tool line pressure regulation
- Hydraulic system maintenance diagnostics
- CNC machine coolant pressure tracking
- Water treatment plant pump systems
Installation guidelines:
Use PTFE tape on threads and tighten to 12-15 N·m torque. Avoid mounting in
direct sunlight or high-vibration areas. For pulsating media, specify
snubber accessory (F-GF-SN1). Calibrate quarterly under 80% max pressure.
| Property | Property Value |
|---|---|
| sku | F-GF5010M |
| Port Size | PT1/4 |
