Airtac F-GF Pressure Gauge F-GF5010P
2、Clear dial markings with selectable pressure units (PSI, bar, kPa, MPa);
3、Versatile mounting configurations and compatible accessories available;
4、Multiple port sizes (1/8", 1/4", 3/8") for flexible pipeline integration.
Category: Pressure Gauges , Brand: AIRTAC , Series: F-GF
AirTAC F-GF5010P Pressure Gauge Technical Details
- Model: F-GF5010P
- Type: Bourdon tube pressure gauge with pulsation damper
- Pressure range: 0-1.0 MPa (customizable up to 60 MPa)
- Accuracy class: ±1.6% F.S (Grade B per EN 837)
- Connection size: G1/4" BSPP female (NPT optional)
- Dial diameter: 50mm (2")
- Case material: 304 stainless steel with polycarbonate window
- Movement material: Brass alloy C3771
- Operating temperature: -20℃ to +60℃ (compensated)
- Proof pressure: 1.5x full scale
- Burst pressure: 3x full scale minimum
- Weight: 480g ±5% (with mounting bracket)
- Dimensions: 50mm(D) × 62mm(H) × 40mm(projection)
- Protection rating: IP54 (splash/dust resistant)
- Vibration resistance: 2.5mm amplitude at 10-55Hz
Industrial-grade pressure measurement instrument featuring shock-absorbing silicone oil filling and anti-parallax dial design. The dual-scale display (MPa/psi) enables quick unit conversion, while the integrated snubber valve protects against pressure spikes. Calibration port allows field verification without system shutdown.
- Pneumatic system pressure monitoring in CNC machines
- Hydraulic power pack performance verification
- Compressed air line diagnostics in automotive workshops
- Process control in plastic injection molding equipment
- Water treatment plant pump systems
Installation guidelines:
Mount vertically ±5° using the rear bracket. For pulsating systems,
install a separate pulsation damper upstream. Avoid exposure to
corrosive gases or direct sunlight. Perform zero-point calibration
every 2,000 operating hours.
| Property | Property Value |
|---|---|
| sku | F-GF5010P |
| Port Size | PT1/4 |
