Airtac F-GF Pressure Gauge F-GF5010Z
2、Clear dial markings with selectable pressure units (PSI, bar, kPa, MPa);
3、Versatile mounting configurations and compatible accessories available;
4、Multiple port sizes (1/8", 1/4", 3/8") for flexible pipeline integration.
Category: Pressure Gauges , Brand: AIRTAC , Series: F-GF
AirTAC F-GF5010Z Pressure Gauge Technical Details
- Model: F-GF5010Z
- Type: Bourdon tube pressure gauge with dampening mechanism
- Pressure range: 0-1.0 MPa (0-145 psi) / Dual scale display
- Accuracy class: ±2.5% F.S (EN 837-1 standard)
- Connection: G1/4" BSPP female thread (stainless steel)
- Dial size: 50mm diameter (chrome-plated brass case)
- Window material: Polycarbonate (3mm thickness)
- Liquid filling: Glycerin (98% purity, anti-vibration)
- Temperature limits:
- Ambient: -20℃ to 60℃
- Medium: Max 80℃ intermittent
- Protection: IP54 (dust/water resistant)
- Weight: 280g ±5g (including packaging)
- Dimensions: 72mm(W) × 72mm(H) × 38mm(D)
- Mounting: Rear entry with 35mm panel cutout
Industrial-grade pressure monitor featuring shock-resistant construction and zero-point calibration mark. The 270° scale rotation allows flexible installation orientations. Enhanced with pulsation damping fluid for stable readings in high-vibration environments. Includes overpressure protection up to 130% FS.
- Hydraulic power unit pressure monitoring
- Pneumatic conveyor system diagnostics
- CNC machine lubrication line supervision
- HVAC refrigerant pressure tracking
- Water treatment plant pump control
Installation guidelines:
Use PTFE tape on threads and tighten to 12-15 N·m torque. Avoid mounting in direct sunlight.
For pulsating media, install pulsation damper upstream. Calibrate quarterly under 25℃ ambient.
| Property | Property Value |
|---|---|
| sku | F-GF5010Z |
| Port Size | PT1/4 |
