Airtac F-GF Pressure Gauge F-GF6004B
2、Clear dial markings with selectable pressure units (PSI, bar, kPa, MPa);
3、Versatile mounting configurations and compatible accessories available;
4、Multiple port sizes (1/8", 1/4", 3/8") for flexible pipeline integration.
Category: Pressure Gauges , Brand: AIRTAC , Series: F-GF
AirTAC F-GF6004B Pressure Gauge Technical Details
- Model: F-GF6004B
- Type: Bourdon tube pressure gauge (liquid-filled)
- Pressure range: 0-1.0 MPa (0-10 bar / 0-145 psi)
- Accuracy class: ±2.5% F.S. (EN 837-1 standard)
- Connection: G 1/4" thread (BSPP)
- Dial diameter: 60mm (2.36")
- Case material: Stainless steel SS304
- Window: Polycarbonate with anti-glare treatment
- Fill fluid: Glycerin (98% purity)
- Temperature limits:
- Ambient: -20℃ to 60℃
- Medium: -20℃ to 80℃ (non-crystallizing)
- Vibration resistance: Up to 2.5g @ 10-55Hz
- Weight: 280g ±5g (including packaging)
- Dimensions: 60mm(D) × 80mm(H) × 25mm(Protrusion)
- Protection rating: IP54 (front face)/IP42 (rear)
Industrial-grade pressure measurement instrument featuring shock-resistant construction and temperature-stable readings. The glycerin-filled chamber dampens pointer oscillation in high-vibration environments. Calibrated for both gaseous and liquid media compatibility (non-corrosive). Includes ±3% overpressure protection.
- Pneumatic conveyor monitoring systems
- Hydraulic power unit pressure verification
- CNC machine tool air supply lines
- Food processing equipment (FDA-compliant wetted parts)
- Water treatment plant pump stations
Mounting advice:
Install with 1/2" clearance behind gauge for maintenance access.
Use PTFE tape on threads - do not overtighten (max 15N·m torque).
For vertical pipes, position gauge within 30° of upright orientation.
| Property | Property Value |
|---|---|
| sku | F-GF6004B |
| Port Size | PT1/4 |
