Airtac F-GF Pressure Gauge F-GF6004M
2、Clear dial markings with selectable pressure units (PSI, bar, kPa, MPa);
3、Versatile mounting configurations and compatible accessories available;
4、Multiple port sizes (1/8", 1/4", 3/8") for flexible pipeline integration.
Category: Pressure Gauges , Brand: AIRTAC , Series: F-GF
AirTAC F-GF6004M Pressure Gauge Technical Details
- Model: F-GF6004M (Radial Connection Type)
- Measurement Range: 0-1.6 MPa (Standard), Customizable up to 60 MPa
- Accuracy Class: ±1.6% F.S (EN 837-1 Standard)
- Connection Thread: G1/4" BSPP (NPT1/4" Optional)
- Case Material: Stainless Steel SS304 with Anti-Corrosion Coating
- Dial Diameter: 60 mm (2.36")
- Window Material: 3mm Tempered Glass
- Movement Type: C-shaped Bourdon Tube Mechanism
- Temperature Limits:
- Ambient: -20°C to +60°C
- Media: Max +80°C (Dry Air/Oil)
- Vibration Resistance: 2.5 m/s² at 10-55 Hz (IEC 60068-2-6)
- Protection Rating: IP54 (Front Face), IP42 (Rear)
- Weight: 320 g ±5% (Including Mounting Hardware)
- Dimensions:
- Body Diameter: 60 mm
- Overall Length: 98 mm (From Connection End)
- Mounting Depth: 18 mm (Thread Engagement)
- Panel Cutout: 55 mm Diameter
- Calibration: Factory-calibrated with NIST Traceable Certificate
Professional-grade pressure gauge featuring shock-absorbing snubber and overpressure protection (130% FS safety margin). The liquid-filled version (F-GF6004M/LF) uses glycerin-filled damping for pulsating systems. Dual-scale bar/psi markings with luminous pointer for low-light environments.
- Pneumatic conveyor line pressure monitoring
- Hydraulic press accumulator systems
- CNC machine tool lubrication units
- Plastic injection molding machines
- Compressed air dryer output verification
Installation Guidelines:1. Use PTFE thread sealant tape (minimum 3 wraps)
2. Tighten with 14-18 N·m torque using backup wrench
3. Avoid side-load forces on connection port
4. For pulsating systems, specify LF version with damping fluid
| Property | Property Value |
|---|---|
| sku | F-GF6004M |
| Port Size | PT1/4 |
