Airtac F-GF Pressure Gauge F-GF6004Z
2、Clear dial markings with selectable pressure units (PSI, bar, kPa, MPa);
3、Versatile mounting configurations and compatible accessories available;
4、Multiple port sizes (1/8", 1/4", 3/8") for flexible pipeline integration.
Category: Pressure Gauges , Brand: AIRTAC , Series: F-GF
AirTAC F-GF6004Z Pressure Gauge Technical Specifications
- Model: F-GF6004Z
- Type: Bourdon tube pressure gauge with zinc alloy case
- Pressure range: 0-600 psi (0-40 bar)
- Accuracy class: ±1.6% full scale (ASME B40.100 Grade B)
- Connection: 1/4" NPT male bottom mount
- Dial size: 63mm (2.5") diameter
- Window material: Polycarbonate with anti-glare treatment
- Case material: Corrosion-resistant zinc alloy (IP54 rating)
- Movement material: 304 stainless steel
- Temperature limits: -20℃ to 60℃ (medium), -10℃ to 50℃ (ambient)
- Pressure media: Compatible with air, oil, water (non-corrosive gases/liquids)
- Weight: 280g ±5g (including packaging)
- Dimensions: 80mm(W) × 80mm(H) × 45mm(D) (body only)
- Mounting depth: 28mm thread engagement
- Vibration resistance: Up to 25Hz at 2g acceleration
Industrial-grade pressure measurement instrument featuring shock-absorbing liquid filling (glycerin optional) for stable readings in high-vibration environments. The 270° scale rotation allows flexible installation orientations. Includes a built-in pulsation damper for hydraulic applications.
- Hydraulic power unit pressure monitoring
- Plastic injection molding machine pressure verification
- Compressed air system maintenance
- Water treatment plant pump controls
- CNC machine lubrication systems
Installation guidelines:
Use thread sealant (Teflon tape recommended) and tighten to 18-22 N·m torque.
Avoid mounting in direct sunlight or near heat sources. For pulsating media,
install a snubber upstream. Calibrate quarterly under continuous vibration conditions.
Maximum instantaneous pressure must not exceed 120% of full scale.
Never apply pressure when the dial glass is damaged.
Requires 5-40μm filtered media to prevent bourdon tube clogging.
| Property | Property Value |
|---|---|
| sku | F-GF6004Z |
| Port Size | PT1/4 |
