Airtac F-GF Pressure Gauge F-GF6010B
2、Clear dial markings with selectable pressure units (PSI, bar, kPa, MPa);
3、Versatile mounting configurations and compatible accessories available;
4、Multiple port sizes (1/8", 1/4", 3/8") for flexible pipeline integration.
Category: Pressure Gauges , Brand: AIRTAC , Series: F-GF
AirTAC F-GF6010B Pressure Gauge Technical Specifications
- Model: F-GF6010B
- Measurement range: 0~1.6 MPa (0~232 PSI)
- Accuracy class: 1.6 (EN 837 standard)
- Connection size: G1/4" (BSPP thread)
- Dial diameter: 60mm ±0.5mm
- Case material: Stainless steel SS304
- Window: Laminated safety glass
- Bourdon tube: Phosphor bronze C5191
- Temperature range:
- Ambient: -25℃ to +70℃
- Medium: -10℃ to +80℃
- Pressure medium: Compatible with air, oil, water (non-corrosive)
- Mounting orientation: Vertical ±5° (recommended)
- IP rating: IP54 (dust protected, water splashes)
- Vibration resistance: ≤2.5m/s² (3-200Hz frequency range)
- Weight: 220g ±10g (excluding accessories)
- Dimensions: 60mm(D) × 60mm(H) × 60mm(W)
Industrial-grade pressure gauge with shock-resistant construction and 270° scale rotation capability. Features anti-parallax dial design and overpressure safety stop (130% FS protection). The hermetically sealed case prevents internal fogging in humid environments. Requires 40μm filtration for abrasive media applications.
- Air compressor pressure monitoring systems
- Hydraulic power unit pressure verification
- Pneumatic tool line pressure regulation
- Industrial boiler auxiliary pressure indication
- CNC machine lubrication system monitoring
Installation guidelines:
Use copper sealing washer (included) for leak-free connection.
Avoid direct sunlight exposure to prevent dial discoloration.
Perform zero-point calibration every 2,000 operating hours.
| Property | Property Value |
|---|---|
| sku | F-GF6010B |
| Port Size | PT1/4 |
