Airtac F-GF Pressure Gauge F-GF6010M
2、Clear dial markings with selectable pressure units (PSI, bar, kPa, MPa);
3、Versatile mounting configurations and compatible accessories available;
4、Multiple port sizes (1/8", 1/4", 3/8") for flexible pipeline integration.
Category: Pressure Gauges , Brand: AIRTAC , Series: F-GF
AirTAC F-GF6010M Pressure Gauge Technical Details
- Model: F-GF6010M
- Type: Bourdon tube pressure gauge with glycerin damping
- Pressure range: 0-10 bar (0-145 psi) / Optional 0-16 bar variant
- Accuracy class: ±1.6% F.S. (ASME B40.1 Grade B)
- Connection type: 1/4" NPT male thread (G1/4 optional)
- Case material: 304 stainless steel with polycarbonate window
- Diaphragm material: Buna-N (NBR) with brass movement
- Operating temperature: -20°C to +60°C (-4°F to 140°F)
- Fill fluid: Glycerin (95% fill ratio, frost-resistant)
- Dial size: 63mm (2.5") diameter
- Weight: 280g ±5g (without packaging)
- Dimensions: 85mm(H) × 63mm(W) × 32mm(D)
- Protection rating: IP54 (dust protected, water splashes)
- Overpressure safety: 130% full scale burst protection
Industrial-grade pressure measurement instrument featuring shock/vibration resistance through liquid-filled housing. The encapsulated movement prevents particulate ingress, with a UV-resistant dial featuring dual scale (bar/psi) markings. Includes zero-adjustment screw and 270° rotation capability for flexible mounting alignment.
- Hydraulic power unit pressure monitoring
- Compressed air receiver tanks (ASME certified)
- Plastic injection molding machine manifolds
- Water jet cutting system pressure verification
- CNC machine lubrication line supervision
Mounting guidance:
Install vertically with connection at 6 o'clock position to prevent fluid pooling.
Use thread sealant (PTFE tape recommended) and tighten to 12-15 N·m torque.
Avoid lateral forces on connection port during installation.
| Property | Property Value |
|---|---|
| sku | F-GF6010M |
| Port Size | PT1/4 |
