Airtac F-GF Pressure Gauge F-GF6010P
2、Clear dial markings with selectable pressure units (PSI, bar, kPa, MPa);
3、Versatile mounting configurations and compatible accessories available;
4、Multiple port sizes (1/8", 1/4", 3/8") for flexible pipeline integration.
Category: Pressure Gauges , Brand: AIRTAC , Series: F-GF
AirTAC F-GF6010P Pressure Gauge Technical Specifications
- Model: F-GF6010P
- Pressure Gauge Type: Bourdon tube mechanical type
- Pressure Range: 0-1.0 MPa (0-10 bar / 0-145 psi)
- Connection Port: G1/4" female thread (ISO228 standard)
- Accuracy Class: ±2.5% of full scale (EN 837-1 compliant)
- Case Material: Stainless steel SS304 with polycarbonate window
- Dial Size: 60mm diameter
- Weight: 200g ±5% (including packaging)
- Dimensions: 60mm(D) × 75mm(H) (body only), 85mm(H) with connection nipple
- Operating Temperature: -20℃ to +60℃
- Vibration Resistance: Up to 2.5g @ 10-150Hz
- Protection Rating: IP54 (dust protected & water splashed resistant)
- Mounting Orientation: Radial (vertical stem installation)
Industrial-grade pressure gauge featuring shock-absorbing structure with liquid-filled option (optional silicone oil FS-3.8). The 270° scale rotation allows flexible viewing angles. Calibration screw accessible through rear port for field adjustments. Includes pulsation-damping mechanism for stable readings in hydraulic/pneumatic systems.
- Air compressor pressure monitoring systems
- Pneumatic control circuit diagnostics
- HVAC refrigerant pressure measurement
- Hydraulic power unit pressure verification
- Industrial boiler auxiliary pressure indication
Installation guidelines:
Use PTFE tape on threads and tighten with 12-15N·m torque. Avoid direct sunlight exposure to prevent dial fading.
For pulsating media, install pulsation damper upstream. Calibrate annually under 75% max pressure.
| Property | Property Value |
|---|---|
| sku | F-GF6010P |
| Port Size | PT1/4 |
