Airtac F-GF Pressure Gauge F-GF6010Z
2、Clear dial markings with selectable pressure units (PSI, bar, kPa, MPa);
3、Versatile mounting configurations and compatible accessories available;
4、Multiple port sizes (1/8", 1/4", 3/8") for flexible pipeline integration.
Category: Pressure Gauges , Brand: AIRTAC , Series: F-GF
AirTAC F-GF Series Pressure Gauge F-GF6010Z Technical Details
- Model: F-GF6010Z
- Type: Bourdon tube pressure gauge with zinc alloy case
- Pressure range: 0-1.0 MPa (customizable up to 10 MPa)
- Accuracy class: ±2.5% F.S (Grade 2.5)
- Port size: G1/4" BSPP female thread
- Dial diameter: 60mm (2.36")
- Measurement medium: Air, non-corrosive gases & hydraulic fluids
- Temperature limits:
- Ambient: -20℃ to +60℃
- Medium: -10℃ to +80℃
- Pressure proof: 1.5x full scale
- Vibration resistance: ≤25Hz with 1.5mm amplitude
- Weight: 280g ±5g (with packaging)
- Dimensions: 76mm(W) × 76mm(H) × 38mm(D)
- Window material: Polycarbonate (anti-shatter)
- Movement lubrication: Silicone-free
- Mounting orientation: Vertical ±5° tolerance
Industrial-grade pressure gauge featuring shock-resistant construction and UV-stable dial markings. The F-GF6010Z's chrome-plated brass movement ensures stable readings in high-vibration environments. Includes a built-in snubber for pulsation damping and 360° rotatable bezel for optimal viewing angle adjustment.
- Air compressor system monitoring
- Pneumatic conveyor line pressure verification
- HVAC refrigerant pressure tracking
- Hydraulic power unit diagnostics
- CNC machine lubrication system checks
Installation guidelines:
Use PTFE tape on threads and tighten with 12-15 N·m torque. Avoid mounting near heat sources (>80℃)
or in direct sunlight. Perform zero calibration after installation using the rear adjustment screw.
Contains glycerin-filled models (F-GF6010Z-G)
for dampened needle movement - verify fluid compatibility before specifying.
| Property | Property Value |
|---|---|
| sku | F-GF6010Z |
| Port Size | PT1/4 |
