Airtac F-GS Pressure Gauge F-GS3004B
2. Precision-engineered dial with clear legibility and multi-unit display options (PSI, bar, MPa, etc.);
3. Flexible mounting configurations supported by modular accessories;
4. Multiple port sizes available (1/8", 1/4") for seamless system integration.
Engineered for industrial automation reliability, the F-GS series combines rapid response dynamics with customizable interface solutions to optimize pneumatic/hydraulic system monitoring.
AirTAC F-GS Pressure Gauge F-GS3004B Technical Details
- Model: F-GS3004B
- Type: Bourdon tube pressure gauge with dual scale
- Pressure range: 0-1.0 MPa (0-145 psi)
- Accuracy class: ±2.5% F.S. (Grade 2.5)
- Connection size: G1/4" BSPP female thread
- Dial diameter: 50mm (2")
- Case material: Stainless steel SS304
- Window material: Polycarbonate (impact-resistant)
- Movement material: Brass alloy
- Temperature limits:
- Ambient: -20℃ to 60℃
- Medium: Max 80℃ (intermittent)
- Weight: 230g ±5g (without accessories)
- Dimensions: 65mm(W) × 65mm(H) × 35mm(D)
- Protection rating: IP54 (dust & water splash resistant)
- Vibration resistance: ≤25Hz with amplitude ≤0.5mm
Industrial-grade pressure measurement instrument featuring a dual-scale dial (MPa/psi) with 270° pointer rotation. The chrome-plated brass movement ensures stable performance in hydraulic and pneumatic systems. Includes a built-in silicone oil damping system (30% fill) for pulsation reduction.
- Air compressor pressure monitoring systems
- CNC machine tool lubrication circuits
- Plastic injection molding machines
- Industrial chillers and cooling systems
- Pneumatic conveyor line pressure verification
Installation guidelines:
Mount vertically with connection port at bottom. Use thread sealant tape (PTFE)
and tighten to 12-15 N·m torque. Avoid lateral forces on connection port.
For pulsating media, install a snubber accessory (F-GS-SN04 recommended).
| Property | Property Value |
|---|---|
| sku | F-GS3004B |
| Port Size | PT1/16 |
