Airtac F-GS Pressure Gauge F-GS3004M
2. Precision-engineered dial with clear legibility and multi-unit display options (PSI, bar, MPa, etc.);
3. Flexible mounting configurations supported by modular accessories;
4. Multiple port sizes available (1/8", 1/4") for seamless system integration.
Engineered for industrial automation reliability, the F-GS series combines rapid response dynamics with customizable interface solutions to optimize pneumatic/hydraulic system monitoring.
AirTAC F-GS3004M Pressure Gauge Technical Details
- Model: F-GS3004M (Stainless Steel Series)
- Type: Bourdon tube pressure gauge with glycerin damping
- Pressure range: 0~1.6MPa (customizable to 0~25MPa)
- Connection: G1/4" BSPP female thread (NPT optional)
- Accuracy class: ±2.5% F.S. (ASME B40.1 Grade B)
- Dial diameter: 60mm (2.36")
- Case material: 304 stainless steel
- Window: Polycarbonate with anti-glare treatment
- Temperature limits:
- Ambient: -20℃ to +60℃
- Medium: -10℃ to +80℃ (non-freezing)
- Vibration resistance: ≤25m/s² (with damping fluid)
- Protection rating: IP54 (dust protected & splash resistant)
- Mounting: Direct stem mount or panel mounting bracket
- Weight: 350g ±5% (with glycerin fill)
- Dimensions:
- Body diameter: 60mm
- Total height: 70mm
- Installation depth: 45mm
Industrial-grade pressure measurement instrument featuring shock-resistant construction and enhanced readability. The glycerin-filled chamber minimizes pointer oscillation in high-vibration environments. Features a 270° scale rotation with dual pressure units (MPa & PSI). Calibration adjustment port located on rear housing.
- Hydraulic power unit pressure monitoring
- Pneumatic system manifold blocks
- HVAC refrigerant pressure verification
- Water treatment plant pump stations
- CNC machine lubrication systems
Installation guidelines:
Mount vertically ±5° to ensure accuracy. Use thread sealant on connections.
Avoid rapid pressure surges exceeding 120% FS. Replace glycerin every 3-5 years.
Contains glycerin -
Do not dispose with regular waste. Compatible media: air, oil, water.
Not for oxygen systems or corrosive gases.
| Property | Property Value |
|---|---|
| sku | F-GS3004M |
| Port Size | PT1/16 |
