Airtac F-GS Pressure Gauge F-GS3004P
2. Precision-engineered dial with clear legibility and multi-unit display options (PSI, bar, MPa, etc.);
3. Flexible mounting configurations supported by modular accessories;
4. Multiple port sizes available (1/8", 1/4") for seamless system integration.
Engineered for industrial automation reliability, the F-GS series combines rapid response dynamics with customizable interface solutions to optimize pneumatic/hydraulic system monitoring.
AirTAC F-GS3004P Pressure Gauge Technical Details
- Model: F-GS3004P
- Type: Bourdon tube pressure gauge with liquid-filled dampening
- Pressure range: 0-1.6 MPa (0-232 psi / 0-16 bar)
- Accuracy class: ±1.6% full scale
- Connection type: 1/4" NPT male thread (G1/4 optional)
- Case material: Stainless steel SS304 with baked enamel finish
- Window material: Tempered glass with anti-glare treatment
- Dial diameter: 63mm (2.5")
- Operating temperature: -20℃ to +60℃ (-4°F to 140°F)
- Protection rating: IP54 (dust protected & water splash resistant)
- Vibration resistance: Up to 25Hz at 2g acceleration
- Weight: 320g ±5% (including packaging)
- Dimensions: 63mm(D) × 80mm(H) × 35mm(protrusion length)
- Mounting orientation: Radial (bottom entry) or axial (back entry)
- Calibration certificate: EN 837-1 compliant (optional)
Industrial-grade pressure measurement instrument featuring shock-absorbing glycerin fill (95% purity) for stable needle movement in high-vibration environments. The chrome-plated brass movement mechanism ensures long-term measurement stability, with a dual-scale display (MPa & psi) for universal readability. Includes a built-in pressure relief vent for overload protection.
- Hydraulic power unit pressure monitoring
- Pneumatic compressor system diagnostics
- Plastic injection molding machine pressure control
- HVAC refrigerant pressure measurement
- Food processing equipment sterilization systems
- CNC machine tool lubrication monitoring
Installation guidelines:
Mount vertically ±5° from upright position. Use thread sealant (PTFE tape recommended)
and tighten with 14-18 N·m torque. Avoid direct sunlight exposure. Perform zero-point
calibration every 2,000 operating hours or 6 months. Not suitable for oxygen systems.
| Property | Property Value |
|---|---|
| sku | F-GS3004P |
| Port Size | PT1/16 |
