Airtac F-GS Pressure Gauge F-GS3010B
2. Precision-engineered dial with clear legibility and multi-unit display options (PSI, bar, MPa, etc.);
3. Flexible mounting configurations supported by modular accessories;
4. Multiple port sizes available (1/8", 1/4") for seamless system integration.
Engineered for industrial automation reliability, the F-GS series combines rapid response dynamics with customizable interface solutions to optimize pneumatic/hydraulic system monitoring.
AirTAC F-GS3010B Pressure Gauge Technical Details
- Model: F-GS3010B
- Type: Bourdon tube pressure gauge with liquid-filled case
- Pressure range: 0-1.0 MPa (customizable up to 60 MPa)
- Connection: G1/4B female thread (NPT1/4 optional)
- Accuracy class: ±1.6% F.S (ASME B40.1 Grade B)
- Dial diameter: 63mm (2.5")
- Case material: Stainless steel SS304
- Window: Polycarbonate with anti-glare treatment
- Fill fluid: Glycerin (98% purity, freeze-resistant)
- Temperature limits:
- Ambient: -20℃ to 60℃
- Medium: -20℃ to 80℃ (non-crystallizing)
- IP rating: IP67 (submersible up to 1m for 30min)
- Mounting: Direct stem mount or panel mount via U-clamp
- Weight: 320g ±5% (with filling fluid)
- Dimensions: 63mm(dia) × 50mm(H) × 85mm(total projection)
Industrial-grade pressure measurement instrument featuring shock-resistant construction and zero-point calibration lock. The silicone oil-filled chamber dampens vibration effects (up to V.H.4 grade) while preventing internal condensation. Includes overpressure protection (130% FS) and reverse polarity prevention design.
- Hydraulic power unit pressure monitoring
- CNC machine tool lubrication systems
- Plastic injection molding machines
- Compressed air distribution lines
- Water treatment plant pump controls
Installation guidelines:
Mount vertically ±2° deviation maximum. Use sealing tape on threads without blocking port hole.
For pulsating media, install snubber accessory (F-GS-SN10). Calibrate quarterly in high-cycling applications.
| Property | Property Value |
|---|---|
| sku | F-GS3010B |
| Port Size | PT1/16 |
