Airtac F-GS Pressure Gauge F-GS3010M
2. Precision-engineered dial with clear legibility and multi-unit display options (PSI, bar, MPa, etc.);
3. Flexible mounting configurations supported by modular accessories;
4. Multiple port sizes available (1/8", 1/4") for seamless system integration.
Engineered for industrial automation reliability, the F-GS series combines rapid response dynamics with customizable interface solutions to optimize pneumatic/hydraulic system monitoring.
AirTAC F-GS3010M Pressure Gauge Technical Details
- Model: F-GS3010M
- Type: Bourdon tube pressure gauge with mechanical indicator
- Pressure range: -0.1~1.6 MPa (vacuum to positive pressure)
- Connection size: G1/4" (BSPP thread)
- Accuracy class: 1.6 (EN 837-1 standard)
- Case material: Stainless steel SS304
- Window material: Polycarbonate (impact-resistant)
- Seal material: NBR (Nitrile rubber)
- Temperature limits:
- Ambient: -20℃ to 60℃
- Medium: Max 80℃ (intermittent 100℃)
- Protection rating: IP54 (dust protected, water splashes)
- Weight: 300g ±5% (including packaging)
- Dimensions:
- Case diameter: 60mm
- Overall height: 80mm
- Mounting depth: 40mm
- Connection length: 12mm thread engagement
Industrial-grade pressure measurement instrument featuring a chrome-plated brass movement mechanism and 270° scale rotation. The shock-resistant design incorporates a liquid-filled option (specify FG-S3010M/L for glycerin-filled version). Calibrated for both gas and liquid media compatibility, with overpressure protection up to 1.3x full scale.
- Pneumatic system pressure monitoring in automation lines
- Hydraulic power unit pressure verification
- Vacuum chamber pressure tracking
- Compressed air distribution systems
- Injection molding machine pressure control
Installation guidelines:
Mount vertically with connection port at bottom to prevent media pooling.
Use PTFE tape on male threads and tighten to 12-15 N·m torque.
Avoid installation near vibration sources - if unavoidable,
specify optional SNUB-04 pulsation damper.
| Property | Property Value |
|---|---|
| sku | F-GS3010M |
| Port Size | PT1/16 |
