Airtac F-GS Pressure Gauge F-GS3010P
2. Precision-engineered dial with clear legibility and multi-unit display options (PSI, bar, MPa, etc.);
3. Flexible mounting configurations supported by modular accessories;
4. Multiple port sizes available (1/8", 1/4") for seamless system integration.
Engineered for industrial automation reliability, the F-GS series combines rapid response dynamics with customizable interface solutions to optimize pneumatic/hydraulic system monitoring.
AirTAC F-GS3010P Pressure Gauge Technical Specifications
- Model: F-GS3010P
- Type: Bourdon tube pressure gauge (glycerin-filled)
- Pressure range: 0-1.0 MPa (0-10 bar / 0-145 psi)
- Accuracy class: ±2.5% F.S. (EN 837-1 standard)
- Port size: G1/8" (BSPP thread) or NPT1/8" optional
- Dial diameter: 60mm (2.36")
- Case material: Stainless steel SS304 with polycarbonate lens
- Movement material: Phosphor bronze
- Seal: Nitrile butadiene rubber (NBR)
- Temperature limits:
- Ambient: -20℃ to 60℃
- Medium: -10℃ to 80℃
- Vibration resistance: ≤25m/s² (3-200Hz)
- Weight: 210g ±5g
- Dimensions: 60mm diameter × 30mm depth (excluding stem)
- Mounting stem length: 15mm (standard), 30mm (optional)
- Protection rating: IP54 (splash and dust resistant)
- Compliance: CE/RoHS certified
Industrial-grade pressure measurement instrument featuring shock-resistant glycerin filling that dampens pointer oscillation in high-vibration environments. The stainless steel case and tempered glass window provide durability against mechanical impacts. Dual-scale display (MPa/psi) with 270° rotation capability for flexible viewing angles.
- Pneumatic system pressure monitoring in CNC machines
- Hydraulic power pack pressure verification
- Compressed air line diagnostics in automotive workshops
- Process control in plastic injection molding equipment
- Energy management systems for industrial chillers
Installation guidelines:
Mount vertically with port orientation downward to prevent media sedimentation.
Use thread seal tape on male connections and tighten to 12-15N·m torque.
Avoid direct sunlight exposure to prevent glycerin discoloration.
| Property | Property Value |
|---|---|
| sku | F-GS3010P |
| Port Size | PT1/16 |
